Samtec TSW Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-106-07-F-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSW Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-106-07-F-D

Name: Samtec TSW Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-106-07-F-D
Brand: Samtec
SKU: 95196
Price: 0.9 USD
Availability: InStock



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	465V
Brand	Samtec
Orientation	Straight
Current	4.7A
Model	TSW-106-07-F-D
Mount Type	Through Hole
Special Features	Many options for optimizing cost and performance with platings and ruggedizing features
Housing Material	Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	TSW
Termination	Through-hole
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board, Wire-to-Board
Contact System	.025" (0.635 mm) square post

Key Features

Features a glass-filled polyester housing for enhanced durability.
Phosphor bronze contacts plated with gold ensure excellent conductivity and corrosion resistance.
Suitable for through-hole mounting with straight orientation and male contact gender.
Operates reliably between -55°C and 125°C with voltage rating up to 465V and current rating of 4.7A.
Unshrouded design offers easy mating and unmating without obstruction.
Provides rugged performance with options to optimize cost through plating and ruggedizing features.
Termination type is solder, ensuring secure connections on PCB assemblies.
Ideal for industrial, electronic, manufacturing, and electrical applications requiring durable and precise PCB connectors.

Product Description

Samtec TSW-106-07-F-D is a high-quality straight through hole pin header featuring 12 contacts arranged in 2 rows with a 2.54 mm pitch. Manufactured with robust glass-filled polyester housing and phosphor bronze contacts plated in gold, this connector ensures reliable electrical performance and long-lasting durability. It supports through-hole mounting and is designed for straightforward vertical orientation with male contact gender.

Operating from a wide temperature range of -55°C to 125°C and rated for 465V and 4.7A current, this pin header supports demanding industrial environments where precision and reliability are critical. The unshrouded design simplifies connector mating and unmating operations.

The connector offers multiple termination and plating options, enabling cost optimization and enhanced ruggedness for various PCB and wire interface applications. It is suitable for board-to-board and wire-to-board connections, catering to electronic, manufacturing, and industrial control systems.

Glass filled polyester housing provides mechanical strength and thermal stability. Gold plated phosphor bronze contacts deliver excellent electrical conductivity and corrosion resistance. Through-hole solder termination ensures secure PCB mounting.

Supports high voltage and current ratings for diverse electronic applications. Unshrouded, straight orientation facilitates easy handling and integration. Extensively tested for long operational life and high mating cycles.

Designed for industrial use cases including electronic assemblies and electrical panel connections.

This Samtec TSW Series pin header is an essential component for high-performance PCB connector solutions, combining durability, reliability, and flexible mounting options with precise engineering standards. Explore more products in the PCB Headers category on EnvMart for comprehensive industrial connector solutions.
