Samtec IPL1 Series Straight Surface PCB Header, 4 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1
Specifications
| Country of Origin | Vietnam |
|---|---|
| Voltage | 954V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.8A |
| Model | IPL1 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | IPL1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a compact 2.54 mm pitch suitable for high-density PCB applications.
- Contains 4 male contacts arranged in 2 rows for reliable electrical performance.
- Housing made from durable Liquid Crystal Polymer material for excellent temperature resistance.
- Contact material is phosphor bronze plated with gold for superior conductivity and corrosion resistance.
- Rated for a current of 3.8A at 95°C and voltage up to 954V, ensuring robust power handling.
- Shrouded design protects contacts and provides polarized mating to prevent misconnection.
- Surface mount mounting style supports efficient PCB assembly processes.
- Operates within a temperature range from -55°C to 125°C, suitable for harsh industrial environments.
Product Description
Samtec IPL1 Series Straight Surface PCB Header IPL1 is engineered as a high-quality PCB connector with 4 male contacts in a 2-row configuration spaced at a 2.54 mm pitch. The header utilizes a Liquid Crystal Polymer housing that offers excellent mechanical and thermal stability, allowing operation from -55°C up to 125°C. Its phosphor bronze contacts plated with gold deliver reliable electrical conductivity and superior resistance to corrosion and wear.
This PCB header is designed for wire-to-board connection systems where durability and electrical performance are critical. The shrouded contacts add a layer of protection and polarity guidance that minimizes connection errors.
Mount type is surface mount ensuring compatibility with modern PCB manufacturing techniques. The header can handle a current rating of 3.8A and voltage up to 954V, making it suitable for a range of industrial, telecommunications, consumer electronics, and instrumentation applications.
Manufactured in Vietnam, the IPL1 series meets demands for long-lasting and precise connectivity solutions in electronics assembly environments. Compact 2.54 mm pitch design supports high-density PCB layouts. Shrouded contacts provide secure and accurate mating.
Durable Liquid Crystal Polymer housing resists heat and mechanical stress. Gold-plated phosphor bronze contacts ensure excellent conductivity and corrosion resistance. Surface mount allows efficient automated placement on PCBs.
Wide operating temperature range for versatile use in industrial and electronic equipment. Robust current and voltage ratings support various power and signal demands.
The Samtec IPL1 Series Straight Surface PCB Header IPL1 is stocked and ready for use in electronics manufacturing and repair. Explore more PCB Headers and connectors in our Electronics Components category on EnvMart to find compatible solutions tailored to your project needs.
