Wurth Elektronik 5 W 28V SIP 3-Pin Voltage Regulator 173010578
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Regulators Wurth Elektronik, Voltage Regulator 5 W 28V SIP 3-Pin RS Stock No |
| Brand | Wurth Elektronik |
| Height | 10.5mm |
| Length | 11.6mm |
| Width | 8.5mm |
| Mount Type | Through Hole |
| Series | 173010 |
| Power Rating | 5W |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP |
| Input Voltage Range | 7 to 28V |
| Polarity | Positive |
| Maximum Input Voltage | 28V |
| Output Voltage | 3.3 or 5V |
| Quiescent Current | 75μA |
| Minimum Input Voltage | 8V |
| Pin Count | 3 |
| Continuous output power | 3.3 or 5W |
Key Features
- The regulator integrates switching power stage, control circuitry, and inductor in one package.
- Input voltage range is from 7V to 28V allowing wide application use.
- Output voltage options include 3.3V or 5V providing flexibility.
- Peak efficiency reaches up to 93%, reducing the need for heatsinks.
- Continuous output power rating is 3.3 or 5 Watts with current capability up to 1 Ampere.
- The package type is SIP with a compact size of 11.6mm length, 8.5mm width, and 10.5mm height.
- Maximum operating temperature rating is 85°C for reliable performance.
- Low quiescent current of 75μA ensures minimal power loss in standby.
Product Description
Wurth Elektronik 173010578 Voltage Regulator is a fixed output voltage, fully integrated DC/DC power supply module designed for industrial and electronic component applications. Its compact SIP package incorporates the switching power stage, control circuitry, and inductor, eliminating the need for external components such as input and output capacitors. This module significantly reduces design complexity and development time, facilitating fast time to market.
Operating with an input voltage range from 7 to 28V, it offers output voltages of either 3.3V or 5V, with continuous output power options of 3.3W or 5W, making it suitable for a range of power management tasks. The regulator's peak efficiency of up to 93% minimizes power dissipation and often removes the necessity for heatsinks and additional assembly parts, ideal for compact and thermally sensitive applications.
The regulator is designed with a SIP 3-pin through-hole configuration, measuring 11.6mm in length, 8.5mm in width, and 10.5mm in height, which facilitates simple PCB mounting. Its positive polarity and low quiescent current of 75μA contribute to power savings, especially in standby states. Capable of handling currents up to 1A and with a maximum operating temperature rating of 85°C, it is robust enough for various industrial, electronic, and power management applications.
This voltage regulator does not meet automotive standards and is manufactured in Taiwan, Province of China. It suits use cases in electronic devices, industrial power supplies, embedded systems, and general power management circuits requiring efficient voltage regulation within compact footprints.
The regulator integrates switching power stage, control circuitry, and inductor in one package. Wide input voltage range from 7V to 28V for flexible application. Dual output voltage configurations: 3.3V or 5V options available.
High efficiency up to 93% reduces heat generation and power loss. Compact SIP 3-pin design for easy through-hole mounting on PCBs. Low quiescent current of 75μA minimizes standby power consumption.
Explore more from Wurth Elektronik in the Voltage Regulators category at EnvMart for high-quality semiconductor power management solutions tailored for precise and reliable electronic circuit design.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this regulator is from 7V to 28V.
This model offers output voltage options of 3.3V or 5V.
The continuous output power rating is either 3.3W or 5W, depending on the configuration used.
It achieves a peak efficiency of up to 93%, which helps to minimize power dissipation.
The maximum operating temperature rating is 85°C.
The quiescent current is 75μA, which helps reduce power loss in standby mode.
This regulator comes in a SIP package type and is designed for through-hole mounting.
The dimensions of this model are 11.6mm in length, 8.5mm in width, and 10.5mm in height.
This unit has a pin count of 3.
No, this voltage regulator does not meet automotive standards.
It is suitable for use in electronic devices, industrial power supplies, embedded systems, and general power management circuits.
This model is manufactured in Taiwan, Province of China.
