STMicroelectronics 5-Channel Linear Voltage Regulator 1A 5V TO-220 3-Pin L7805ABV
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 9.15mm |
| Length | 10.4mm |
| Model | L7805ABV |
| Width | 4.6mm |
| Mount Type | Through Hole |
| Output type | Fixed |
| Series | L78xx |
| Output Current | 1A |
| Maximum Operating Temperature | 125°C |
| Package Type | TO-220 |
| Load Regulation | 100 mV |
| Minimum Operating Temperature | -40°C |
| Polarity | Positive |
| Regulator Type | Linear |
| Number of outputs | 5 |
| Maximum Input Voltage | 35V |
| Output Voltage | 5V |
| Quiescent Current | 4.3mA |
| Line Regulation | 50 mV |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
Key Features
- Features a linear regulator type with fixed positive polarity output.
- Incorporates thermal overload and safe operating area protection for enhanced reliability.
- Designed to operate with input voltage up to 35V within the -40°C to 125°C temperature range.
- Constructed in a TO-220 through-hole package with 3 pins for easy PCB mounting.
- Designed for industrial power management applications requiring up to 1.5A current delivery.
- Low quiescent current of 4.3mA minimizes power loss during operation.
- Load regulation of 100mV and line regulation of 50mV ensure stable voltage output.
- Meets RoHS standards confirming environmental compliance.
Product Description
STMicroelectronics L7805ABV is a 5-Channel Linear Voltage Regulator designed for robust power management within electronic and industrial systems. It delivers a fixed output voltage of 5V with a maximum output current of 1A, suitable for a wide range of applications requiring stable DC voltage.
The device utilizes a linear regulator architecture featuring positive polarity output in a durable TO-220 3-pin through-hole package, allowing easy integration into PCB designs. It supports input voltages up to 35V and operates reliably from -40°C to 125°C, making it versatile across various operating environments.
Protection features include thermal overload shutdown and safe operating area (SOA) protection, increasing the device's reliability under demanding conditions. The regulator also offers line regulation of 50mV and load regulation of 100mV, ensuring consistent voltage under fluctuating load and line conditions.
With a low quiescent current of 4.3mA, the L7805ABV reduces power wastage during idle states. It is compliant with RoHS environmental standards, supporting sustainable electronics design.
This regulator is commonly used in industrial power management, embedded systems, and electronics equipment requiring steady 5V supplies. Its 5-channel configuration makes it suitable for applications necessitating multiple voltage outputs from a single device package.
Features a linear regulator type with fixed positive polarity output. Incorporates thermal overload and SOA protection for device safety. Supports input voltage up to 35V and output current up to 1.5A. Available in robust TO-220 3-pin package for through-hole PCB mounting.
Operates reliably between -40°C and 125°C. Maintains low quiescent current of 4.3mA to save power. Ensures voltage stability with load and line regulation of 100mV and 50mV respectively. RoHS compliant for environmental safety.
Explore the STMicroelectronics category on EnvMart for more high-quality power management ICs and Voltage Regulators from top manufacturers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The L7805ABV provides a fixed output voltage of 5V and can deliver a maximum output current of 1A.
This voltage regulator can support input voltages up to 35V.
It operates reliably within a temperature range of -40°C to 125°C.
The dimensions of the TO-220 package are 10.4mm in length, 4.6mm in width, and 9.15mm in height.
It provides a fixed positive polarity output.
The L7805ABV includes thermal overload shutdown and safe operating area (SOA) protection for enhanced reliability.
The quiescent current is 4.3mA, which helps minimize power loss during operation.
It maintains voltage stability with load regulation of 100mV and line regulation of 50mV.
This model features 5 outputs, making it suitable for applications requiring multiple voltage outputs.
The country of origin for the L7805ABV is India.
Yes, it is compliant with RoHS standards, confirming its environmental safety.
It is designed for through-hole mounting, allowing easy integration into PCB designs.
