Wurth Elektronik 1317 Series PCB Terminal Block, 8-Contact, 5 mm Pitch, Through Hole, Horizontal, Grey 691131710008
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 450V ac |
| Brand | Wurth Elektronik |
| Colour | Grey |
| Orientation | Horizontal |
| Current | 22A |
| Length | 40mm |
| Depth | 15.5mm |
| Width | 8.5mm |
| Mount Type | Through Hole |
| Series | 1317 |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | cULus, RoHS, VDE |
| Number of Contacts | 8 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 12AWG |
Key Features
- Features 8 contacts for multi-channel connections.
- 5 mm pitch enhances efficient PCB layout and flexibility.
- Through hole mounting ensures stable and reliable installation.
- Supports horizontal entry with robust pressure clamp system.
- Accommodates wire sizes from 0.05 mm² to 3.31 mm² (30 to 12 AWG).
- Rated for currents up to 22A and voltages up to 450V AC.
- Housing made from grey UL94-V0 polycarbonate for durability and safety.
- Divisible housing design offers adaptability for custom applications.
Product Description
Wurth Elektronik 691131710008 PCB Terminal Block is a high-quality, industrial-grade connector designed for reliable electrical termination in various electronic assemblies. As part of the 1317 series, this terminal block boasts 8 contacts, a 5 mm pitch, and through hole mounting, making it ideal for multi-channel PCB applications requiring efficient layout and secure connectivity.
Features a horizontal entry configuration using a pressure clamp system, ensuring a safe and firm connection using an M2.5 screw and zinc plated steel clamp. The terminal accommodates both solid and stranded wire sizes from 0.05 mm² to 3.31 mm² (30 to 12 AWG), allowing flexibility in wire selection for different circuit requirements.
Capable of handling maximum current up to 22A and voltages up to 450V AC, providing robustness for industrial and power electronics use. Housing is constructed from grey UL94-V0 polycarbonate material, offering flame resistance, mechanical durability, and compliance with stringent safety standards.
Divisible design enables customization and scalability, supporting specialized PCB designs and modular configurations.
This terminal block is suitable for applications such as automation systems, control panels, industrial power supplies, HVAC controls, and laboratory instrumentation. Its compliance with RoHS, VDE, and cULus certifications ensures it meets global regulatory requirements and quality standards for electronics manufacturing.
Dimensions are compact, with a length of 40 mm, width of 8.5 mm, and depth of 15.5 mm. The 1-row layout simplifies mounting and wiring in dense electronic environments. Packaged for easy installation; each unit provides a reliable interface between PCB and external wiring.
Industrial applications: Electronics manufacturing, automation, laboratory, commercial panel building, and instrumentation. For more industrial connectors and terminal blocks, browse the PCB Terminal Block category from Wurth Elektronik at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a maximum current of 22A and a maximum voltage of 450V AC.
It can accommodate wire sizes ranging from 0.05 mm² to 3.31 mm², which corresponds to 30 AWG to 12 AWG.
The contacts in this terminal block have a pitch of 5 mm, which enhances efficient PCB layout.
It features through hole mounting, ensuring stable and reliable installation on PCBs.
The housing is made from grey UL94-V0 polycarbonate, providing flame resistance and mechanical durability.
The dimensions are 40 mm in length, 8.5 mm in width, and 15.5 mm in depth.
It complies with RoHS, VDE, and cULus certifications, ensuring it meets global regulatory requirements.
This model supports horizontal entry with a robust pressure clamp system for secure connections.
Yes, it features a divisible housing design that allows for customization and scalability for specialized PCB designs.
It is suitable for applications such as automation systems, control panels, industrial power supplies, HVAC controls, and laboratory instrumentation.
The contacts are oriented horizontally, which is suitable for various PCB layouts.
This terminal block features 8 contacts, allowing for multi-channel connections.
