Wurth Elektronik WR- Series Vertical Surface PCB Header, 3 Contacts, 3 mm Pitch, 1 Row, Shrouded, 250V, 5A, Liquid MPC3

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR- Series Vertical Surface PCB Header, 3 Contacts, 3 mm Pitch, 1 Row, Shrouded, 250V, 5A, Liquid MPC3

Name: Wurth Elektronik WR- Series Vertical Surface PCB Header, 3 Contacts, 3 mm Pitch, 1 Row, Shrouded, 250V, 5A, Liquid MPC3
Brand: Wurth Elektronik
SKU: 89273
Price: 3.45 USD
Availability: InStock



Category PCB Header Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	250V
Brand	Wurth Elektronik
Orientation	Vertical
Current	5A
Model	MPC3
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Copper Alloy
Series	WR-MPC3
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	3mm
Contact Plating	Tin
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Features WR-MPC3 series with a vertical, surface mount configuration.
Equipped with 3 male contacts with a pitch of 3 mm for reliable wire-to-board connectivity.
Shrouded design enhances safety and alignment during PCB installation.
Constructed from liquid crystal polymer housing and copper alloy contacts with tin plating.
Supports maximum operating current up to 5A and voltage up to 250V.
Operates within a temperature range from -40°C to 105°C.
Solder termination type suitable for surface mount applications.
Complies with RoHS standards, offering high reliability for industrial and electronic assembly.

Product Description

Wurth Elektronik 662303131822 WR-MPC3 Series PCB Header is designed for demanding electrical and electronic applications, offering a robust wire-to-board connector solution that meets modern industrial standards. This vertical surface mount header features a shrouded single row, providing improved alignment and protection for mating contacts, making it ideal for use in PCBs where mechanical stability and reliable electrical connection are essential.

Equipped with 3 copper alloy male contacts on a 3 mm pitch, it supports continuous operation at up to 5A and 250V, suitable for high-density electronic designs and circuits requiring compact yet durable connectors. The housing is manufactured from liquid crystal polymer (LCP), delivering strong thermal and mechanical resistance, and the contacts are tin-plated to ensure corrosion resistance and long-term electrical performance.

WR-MPC3 series vertical surface PCB header for wire-to-board connectivity. 3 contacts spaced at 3 mm pitch for robust signal or power distribution. Shrouded single row design for safe and precise mating. Surface mount solder termination for efficient PCB assembly processes.

Operating temperature range from -40°C to 105°C for industrial reliability. Housing material: LCP, contact material: copper alloy, plating: tin. Rated at 5A current and 250V voltage for versatile electrical use. Complies with RoHS environmental standards (no hazardous substances present).

This connector is widely used in industrial automation, instrumentation, control panels, telecom hardware, and advanced consumer electronics. It is ideal for environments requiring high density and rugged connectivity, such as manufacturing equipment, laboratory devices, and precision instrumentation.

For further selection and browsing, explore the PCB Header category for a comprehensive range of wire-to-board connectors, shrouded headers, and related PCB assembly solutions from Wurth Elektronik and other leading brands.
