TDK-Lambda CC-E Series DC/DC Converter 5V DC Output, 0.3 mA, 36V DC Max Input, 18V Min Input, 1.5 W, Surface CC1R5-2405SR-E
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda CC-E DC/DC Converter, 5V dc/ 0 |
| Brand | TDK-Lambda |
| Efficiency | 77% |
| Length | 16.51mm |
| Model | CC1R5-2405SR-E |
| Depth | 8.8mm |
| Width | 16.6mm |
| Mount Type | Surface |
| Series | CC-E |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 1.5W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 0.3mA |
| Output Voltage Adjustment Range | 6 V |
| Isolation Voltage | 500V ac |
Key Features
- Provides 5V DC regulated output with 0.3 mA output current.
- Accepts wide input voltage of 18V DC minimum to 36V DC maximum for versatile usage.
- Offers 1.5 W maximum output power suitable for compact PCB designs.
- Surface mount package optimizes board space and is lightweight.
- Operates reliably from -40°C to +85°C for harsh environments.
- Features 77% efficiency and 500V AC isolation voltage for safety.
- Open frame design with seven pins for easy system integration.
- Ideal for test, measurement, broadcast, process control, and industrial systems.
Product Description
The TDK-Lambda CC1R5-2405SR-E is a single output DC/DC converter from the proven CC-E series, offering dependable performance and efficient power conversion. With a regulated 5V DC output and up to 0.3 mA output current, it is engineered for applications where stable low voltage supply and robust operation are required. The device accepts a broad input voltage range from 18V DC minimum to 36V DC maximum, making it suitable for various electronic systems and industrial installations.
This converter features a maximum output power of 1.5 W, a surface mount package form factor for compact integration, and benefits from a lightweight metal case that minimizes radiated EMI. With an efficiency rating of 77%, it supports energy-saving operations and ensures reduced heat dissipation.
Designed to withstand demanding environments, the CC1R5-2405SR-E operates reliably across a wide temperature range, from -40°C to +85°C. Its open frame (no potting) construction and seven-pin layout allow for easier PCB design and straightforward system configuration, requiring no external components for basic operation.
The converter boasts 500V AC isolation voltage for enhanced safety in electronic circuits and is suitable for installations where isolation between input and output is critical. The CC-E series includes multiple voltage and power combinations, and this model is specifically tailored for compact test and measurement setups, broadcasting equipment, process control modules, and general industrial power supply needs.
Key applications include powering sensitive analog and digital circuits, supporting measurement devices, and enabling reliable operation in continuous industrial processes. Its compact footprint reduces PCB area while offering a robust solution for engineers and system integrators.
Typical use cases encompass laboratory instrumentation, signal processing in broadcast systems, sensor interfaces in process control, and general-purpose industrial electronics. Browse other DC-DC converters and TDK-Lambda solutions in the Electronics & Electricals > Converters > DC-DC Converter category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a regulated output voltage of 5V DC.
The maximum input voltage for the CC1R5-2405SR-E is 36V DC.
It has an efficiency rating of 77%.
The operating temperature range is from -40°C to +85°C.
This model has one output channel.
The maximum output power is 1.5 W.
It comes in a surface mount package type, which optimizes board space.
The isolation voltage is 500V AC, providing enhanced safety in electronic circuits.
The dimensions are 16.51 mm in length, 16.6 mm in width, and 8.8 mm in depth.
It is suitable for applications in test, measurement, broadcast, process control, and industrial systems.
This model has seven pins for easy system integration.
The minimum input voltage is 18V DC.
