TE Connectivity Surface Signal Relay 12V DC, 2A, DPDT, Surface Mount, IM26GR

TE Connectivity IM26GR Surface Signal Relay is an advanced component designed for reliable signal switching in electronic and automation systems. This relay features a dual pole double throw (DPDT) configuration, making it ideal for applications requiring multiple switching paths and precise control.

The relay utilizes a 12V DC coil voltage, providing stable and efficient actuation suited for telecom, industrial, and automation circuit environments. With a 2A switching current capability, the IM26GR model is well-suited for low-power signals and ensures consistent operational performance.

Its surface mount design and solder terminal type allow seamless integration into printed circuit boards (PCBs), supporting compact layouts and modern electronic assembly practices. The relay is equipped with gold-plated bifurcated contacts, maximizing conductivity and minimizing signal degradation over extended use. Hermetically sealed construction further protects internal components from humidity, dust, and environmental stress.

IM26GR supports switching voltages up to 250V AC and 220V DC, providing interface flexibility and compatibility with a wide range of signal conditioning equipment. Mechanical properties include a streamlined enclosure measuring just 10mm in length, 6mm in width, and 5.65mm in height, facilitating installation in space-constrained locations.

Additional technical highlights include a 50mW coil power, 2800Ω coil resistance, and robust insulation exceeding 109Ω at 500V DC. The relay is engineered for high mechanical shock resistance, up to 300G functional and 500G survival, and boasts an operating temperature range from -40°C to +85°C, making it suitable for challenging operational conditions.

Safety and compliance are assured with RoHS conformity and UL approval. The IM26GR relay is rated IP67, further increasing its durability and suitability for demanding industrial environments. Common use cases include telecom equipment, signal processing circuits, industrial automation controllers, laboratory instrumentation, and commercial electronics requiring precise, low-profile relay integration.

DPDT signal relay with 12V DC coil voltage. 2A switching current for reliable low-power applications. Surface mount with gullwing legs for PCB installation. Gold-plated contacts for high conductivity. Compact dimensions suited for dense electronic assemblies.

Hermetically sealed for environmental robustness. Wide operating temperature range for industrial reliability. UL approved and RoHS compliant for regulatory adherence. Explore more in Signal Relays and TE Connectivity electronic components at EnvMart for trusted industrial and commercial automation solutions.
