HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 3 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8420342

HARWIN M80-8420342 is a Datamate L-Tek Series right angle through-hole PCB header designed for demanding electronic and industrial applications. This connector features three gold-plated phosphor bronze contacts, spaced 2 mm apart, within a single row and shrouded housing for enhanced protection against environmental stress.

The right angle orientation makes this header ideal for compact PCB layouts where space and connectivity precision are essential. Mounting is achieved via through-hole pins, ensuring sturdy mechanical retention and reliable electrical connections, even in high vibration and shock environments.

The shrouded body construction improves mating accuracy, prevents misalignment, and provides additional durability for repeated cycles, sustaining performance over time. Gold-plated contacts offer optimal conductivity and corrosion resistance, ensuring signal integrity in critical circuitry.

Operating across a wide temperature range from -55°C to 125°C, the Datamate L-Tek header suits challenging industrial, laboratory, automotive, and aerospace setups. The connector is further distinguished by its compliance with key standards, including BS9525-F0033, MIL C 55302, and CEC 75101-008, supporting requirements for commercial off-the-shelf (COTS) applications.

Features a robust right-angle orientation suitable for PCB board mounting. Accommodates 3 contacts with a 2 mm pitch for compact electronic designs. Utilizes gold-plated phosphor bronze contacts to ensure high conductivity and reliability.

Shrouded design improves connector protection and mating alignment in demanding environments. Suitable for board-to-board and wire-to-board connections in high vibration, shock, or harsh industrial applications. Operates from -55°C to 125°C for wide-ranging electronic and industrial environments.

Through-hole mounting ensures secure PCB attachment and strong electrical connections. Complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 industry standards.

This connector is widely used in electronics manufacturing, industrial control systems, laboratories, and engineering setups where reliable signal transfer and mechanical resilience are crucial. HARWIN's Datamate series is valued for its high reliability, longevity, and compatibility with known industry equivalents.
