Amphenol Communications Solutions EconoStik Series Right Angle Through Hole Pin Header 6 Contacts, 2.54 10129382-906002BLF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Current | 3A |
| Model | 10129382-906002BLF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | EconoStik |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS compliant, Lead-Free |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 5.84mm |
Key Features
- Delivers secure board-to-board connections for industrial control, metering, POS, test and surveillance applications.
- Features 6 male contacts in two rows with right angle orientation for space-efficient circuit design.
- Includes gold-plated brass contacts and high-temperature thermoplastic housing for durability and electrical conductivity.
- Handles up to 3A current and 1500V voltage, ensuring reliable operation in demanding environments.
- Supports through-hole solder termination and is RoHS compliant and lead-free.
- Designed for 2.54 mm row pitch with customized mating and tail lengths available for flexibility.
Product Description
The Amphenol Communications Solutions EconoStik Series Pin Header, model 10129382-906002BLF, is a board-to-board connector engineered for high-reliability applications. Offering 6 contacts, each spaced at a 2.54 mm pitch, this right-angle through-hole connector is ideal for industrial control, test equipment, metering, POS systems, surveillance setups, and vending machines.
Constructed with high-temperature thermoplastic housing and gold-plated brass contacts, the pin header ensures exceptional electrical conductivity, robust durability, and resistance to heat and wear, making it suitable for both commercial and industrial electronics.
This connector is rated for 3A current and 1500V voltage, designed to accommodate demanding circuits. The 6 male contacts are distributed in two rows, with unshrouded construction for easy mating and custom polarization available. The mating pin length measures 5.84 mm, supporting versatile PCB designs.
Through-hole mount and solder termination guarantee stable attachment to circuit boards, while RoHS compliance ensures eco-friendly design. Tailored mating and tail lengths are available, accommodating specific PCB layouts and assembly requirements.
The EconoStik Series supports a wide range of board-to-board connections in industrial automation, instrumentation, electronic metering, and embedded systems. Its right-angle configuration optimizes space utilization on densely populated PCBs.
Key features include high-temperature thermoplastic material, gold contact plating, tested for 50 mating cycles, and compliance with up-to-date electronic component standards.
Engineers and designers can rely on the Amphenol Communications Solutions 10129382-906002BLF for robust, precise, and long-lasting PCB interconnections in critical industrial and commercial applications.
Explore more PCB headers and advanced connectivity solutions in the Electronics Components category at EnvMart - where engineered quality meets reliability.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a voltage of 1500V, making it suitable for demanding electrical applications.
This model can handle up to 3A of current, ensuring reliable operation in various circuits.
The contacts are spaced at a pitch of 2.54 mm, which is standard for many PCB applications.
It features 6 male contacts arranged in two rows, designed for efficient board-to-board connections.
It is constructed with a high-temperature thermoplastic housing and gold-plated brass contacts for enhanced electrical conductivity and durability.
This pin header uses solder termination, which ensures stable attachment to circuit boards.
The maximum operating temperature is 105°C, while the minimum is -55°C, allowing it to function in a wide range of environments.
Yes, it is RoHS compliant and lead-free, adhering to environmental regulations for electronic components.
The mating pin length measures 5.84 mm, facilitating versatile PCB designs and connections.
It supports through-hole mounting, which is common for securing components on PCBs.
The contacts are oriented in a right angle configuration, optimizing space utilization on densely populated PCBs.
It is suitable for industrial control, metering, POS systems, test equipment, and surveillance applications.
