TDK EMC Filter Panel Mount 50A 520V AC Screw Termination 3 Phase 50/60 Hz B84143A0050R107
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 80mm |
| Length | 188mm |
| Model | B84143A0050R107 |
| Depth | 84.5mm |
| Mount Type | Panel Mount |
| Operating Frequency | 50, 60Hz |
| Series | B84143A*R107 |
| Maximum Operating Temperature | 100°C |
| Number Of Stages | 1 |
| Resistance | 1.1mΩ |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 50A |
| Number of Phases | 3 |
| Leakage Current | 3.4mA |
| Maximum Voltage | 520V ac |
| Standards/Approvals | UL1283 |
| Termination Style | Screw |
Key Features
- Rated for maximum current of 50A to effectively suppress electromagnetic interference.
- Supports high voltage operation up to 520V AC, suitable for industrial power line applications.
- Panel mount design with screw terminals ideal for secure, robust installation.
- Operates across 50 Hz and 60 Hz frequencies, compatible with worldwide power systems.
- Three phase configuration ensures comprehensive EMI filtering in multi-phase circuits.
- Compact build with length of 188mm, height of 80mm, and depth of 84.5mm for space-saving integration.
- Low leakage current of 3.4mA helps maintain overall system safety and compliance.
- UL1283 approved for reliable performance and quality assurance.
Product Description
TDK B84143A0050R107 is a high-performance panel mount EMC filter engineered for advanced noise suppression in industrial power line applications. Designed to mitigate electromagnetic interference, this filter is rated for a maximum current of 50A and operates at a voltage of up to 520V AC, making it suitable for demanding environments where power quality and compliance are essential.
This EMC filter features a robust panel mount construction with screw termination, ensuring secure installation and easy maintenance in control cabinets, distribution panels, and machinery systems. The three-phase configuration delivers comprehensive filtering, reducing electromagnetic emissions and improving the operational reliability of connected equipment.
Operating efficiently across both 50 Hz and 60 Hz power grids, the B84143A0050R107 is compatible with a broad range of international industrial and commercial systems. The filter integrates a compact design, measuring 188mm in length, 80mm in height, and 84.5mm in depth, which allows for convenient placement even in limited spaces.
With a leakage current of just 3.4mA, this filter is well-suited for sensitive environments and meets stringent safety requirements. Its degree of protection at the front side, rated at IP40, further underscores its suitability for rigorous applications. The filter incorporates advanced cost-optimized construction, balancing reliability with economic efficiency.
Compliant with UL1283 standards, the EMC filter assures stable performance and certification for use in demanding commercial, industrial, automation, and electronics setups. The product's compact design and ease of installation make it a preferred choice for electronic equipment manufacturers, control panel engineers, and system integrators.
Typical use cases include industrial automation, manufacturing equipment, HVAC systems, power distribution panels, laboratory instrumentation, and commercial power management installations requiring stringent EMI suppression.
Explore TDK’s full range of EMI and EMC filtering solutions in the Electronics & Electricals category on EnvMart.
Explore more products in our Noise Filter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this EMC filter is 50A, allowing it to effectively suppress electromagnetic interference in industrial applications.
This model supports a maximum operating voltage of 520V AC, making it suitable for high voltage industrial applications.
It operates efficiently across both 50 Hz and 60 Hz frequencies, ensuring compatibility with worldwide power systems.
The filter features a panel mount design with screw terminals, ensuring secure and robust installation.
This unit has a compact design with dimensions of 188mm in length, 80mm in height, and 84.5mm in depth.
This EMC filter is configured for three-phase operation, providing comprehensive EMI filtering in multi-phase circuits.
The leakage current for this model is 3.4mA, which helps maintain overall system safety and compliance.
The filter operates within a temperature range of -25°C to 100°C, allowing it to function in various environmental conditions.
This filter is compliant with UL1283 standards, ensuring reliable performance and quality assurance.
Typical use cases include industrial automation, manufacturing equipment, HVAC systems, and power distribution panels requiring stringent EMI suppression.
The resistance value of this EMC filter is 1.1mΩ, which contributes to its effective noise suppression capabilities.
The country of origin for this EMC filter is Hungary.
