Labtron LBPS-A10 Brightfield Pathology Slide Scanner
Specifications
| Country of Origin | UK |
|---|---|
| Resolution | ≤ 0.25 μm/pixel (20x) / ≤ 0.125 μm/pixel (40x) |
| Brand | Labtron |
| Focus | Automatic Z-axis focusing using a piezoelectric ceramic motor / accuracy of 10 μm |
| Model | LBPS-A10 |
| Weight | 310 Kg |
| Type of Product | Pathology Slide Scanner |
| Scanning Speed | Less than 25 s (20x — 15 × 15 mm) / Less than 90 s (40x — 15 × 15 mm) |
| Magnification | 20x / 40x |
| Objective | 20x NA 0.8 / 40x NA 0.95 |
| Dimension (L × W × H) | 1399 × 859 × 922 mm |
| Scanning Capacity | 1200 |
| Acceptable Slides | 1 × 3 inch |
| Light Source Scanning | LED long-life light source |
| Sample Loading Method | Automatic loading by mechanical arm / with electric control |
| Sample Identification | Automatic identification / manually adjustable area |
| Scanning Mode | Single-slice scanning / multi-slice scanning |
| Multi-layer Scanning | Yes |
| Brightfield Scanning Time | ≤ 15 s (20x objective lens — 15 × 15 mm area) |
| Image Format | TIFF / SVS |
| Browsing Mode | Support local software / browser / mobile viewing |
Key Features
- High Resolution
- Quality Optics
- LED Illumination
- Precise Focusing
- Z-Stacking
Product Description
Brightfield Pathology Slide Scanner LBPS-A10 has a scanning capacity of 1,200 slides, enhancing efficiency in large-scale operations. It has rapid scanning speeds, completing a 15 × 15 area under 25 s at 20x and under 90 s at 40x magnification. The device supports both single and multi-slide scanning, compatible with standard 1 × 3-inch slides. Its electric-controlled mechanical arm automates loading, streamlining sample handling efficiently. Our scanner supports various image formats and viewing via local software, web browsers, and mobile devices.
Applications:
Our Brightfield Pathology Slide Scanner LBPS-A10 is a high-throughput, fully automatic device designed for clinical applications, education, telepathology, and scientific research.
