Lutron CM-9930R Clamp Multimeter
Specifications
| Brand | LUTRON |
|---|---|
| Power Supply | 9V Battery |
| Type | Digital Clamp Multimeter |
| Dimensions | 73 x 255 x 38 mm |
| Model | CM-9930 |
| Weight | 380 g |
| Communication Interface | RS232/USB |
| Resistance ranges | 400 Ω / 4 kΩ / 40 kΩ / 400 kΩ / 4 MΩ / 40 MΩ |
| Measurements | AC/DC Voltage / AC/DC Current / Resistance / Duty Cycle / Capacitance / Frequency / Diode / Continuity |
| True RMS | Yes |
| Max Conductor Diameter | 51 mm |
| Safety Compliance | IEC 1010-1 / Cat III 1000V |
| Voltage Ranges | 400 mV / 4 V / 40 V / 400 V / 1000 V |
| Current Ranges (Direct) | 400 uA / 4000 uA / 40 mA / 400 mA |
| Current Ranges (Clamp) | 400 A / 2000 A |
| Frequency Ranges | 5 Hz / 50 Hz / 500 Hz / 5 kHz / 50 kHz / 100 kHz |
| Capacitance Ranges | 50 nF / 500 nF / 5 uF / 50 uF |
Key Features
- AC/DC current and voltage measurement.
- Resistance, duty cycle, capacitance, and frequency measurement.
- True RMS.
- Diode and continuity testing.
- RS232/USB PC interface.
- Max conductor diameter 51mm
Product Description
The Lutron CM-9930R is a digital clamp multimeter with a communication interface. It measures AC/DC current and voltage, resistance, duty cycle, capacitance, and frequency. It features True RMS, diode and continuity testing, relative measurement, data hold, auto-off, battery voltage measurement, zero setting, overload protection, and splash protection. It supports customized adapters for various measurements. The maximum conductor diameter is 51mm. It complies with IEC 1010-1/Cat III 1000V. The device offers RS232/USB PC computer interface, and is powered by a 9V battery.
Available on EnvMart, these Multimeters are equipped with advanced circuitry to accurately measure voltage, current, resistance, and more. Lutron Multimeters are trusted for their precision, durability, and multifunctional capabilities, making them essential tools for electricians, technicians, and engineers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can measure AC/DC voltage, AC/DC current, resistance, duty cycle, capacitance, frequency, as well as perform diode and continuity testing.
The maximum conductor diameter that the Lutron CM-9930R can accommodate is 51 mm.
It is powered by a 9V battery.
The dimensions are 73 x 255 x 38 mm, and it weighs 380 g.
Yes, this model features True RMS measurement capabilities.
It complies with IEC 1010-1 / Cat III 1000V safety standards.
The Lutron CM-9930R includes a /USB communication interface for connecting to a PC.
The resistance measurement ranges are 400 Ω, 4 kΩ, 40 kΩ, 400 kΩ, 4 MΩ, and 40 MΩ.
It can measure direct current ranges of 400 µA, 4000 µA, 40 mA, and 400 mA, as well as clamp current ranges of 400 A and 2000 A.
The frequency measurement ranges are 5 Hz, 50 Hz, 500 Hz, 5 kHz, 50 kHz, and 100 kHz.
It can measure capacitance in the ranges of 50 nF, 500 nF, 5 µF, and 50 µF.
It features data hold, auto-off, battery voltage measurement, zero setting, and overload protection for enhanced usability.
