Hioki Digital Multimeter DT4256
Specifications
| Country of Origin | Japan |
|---|---|
| DC Voltage range | 600.0 mV to 1000 V / 5 ranges / ±0.3 % rdg. ±3 dgt. |
| AC Voltage Range | 6.000 V to 1000 V / 4 ranges / 40 Hz - 1 kHz / ±0.9 % rdg. ±3 dgt. (True RMS) |
| Capacitance Range | 1.000 μF to 10.00 mF / 5 ranges / ±1.9 % rdg. ±5 dgt. |
| Resistance Range | 600.0 Ω to 60.00 MΩ / 6 ranges / ±0.7 % rdg. ±3 dgt. |
| Display | 4-digit LCD / max. 6000 digits / bar graph |
| Frequency range | 99.99 Hz (≥5 Hz) to 99.99 kHz / 4 ranges / ±0.1 % rdg. ±1 dgt. |
| Diode Test | ≤5.0 V open terminal voltage / ≤0.5 mA test current |
| Brand | HIOKI |
| Power Supply | 4× LR03 alkaline batteries / 130 hours (backlight OFF) |
| Dimensions | 84 × 174 × 52 mm |
| Model | DT4256 |
| Weight | 390 g (with batteries and holster) |
| Functions | Filter / hold / MAX/MIN/AVG display / relative display / auto-power save / USB communication (optional) |
| Included Accessories | Test lead L9207-10 / Holster / Instruction manual / 4× LR03 batteries |
| DC Current range | 60.00 mA to 10.00 A / 4 ranges / ±0.9 % rdg. ±3 dgt. |
| AC Current range | 600.0 mA to 10.00 A / 3 ranges / ±1.4 % rdg. ±3 dgt. (True RMS) |
| Continuity Check | ON - ≤25 Ω (Buzzer / Red LED) / OFF - ≥245 Ω / Response time - ≥0.5 ms |
| Refresh Rate | 5 times/s (varies by function) |
| AC Current Range (Clamp Probe) | 10.00 A to 1000 A / 7 ranges / ±0.9 % rdg. ±3 dgt. (True RMS) |
| Auto AC/DC Voltage Detection | Yes |
| Voltage Detection (50/60 Hz) | Hi - AC 40 V to 600 V / Lo - AC 80 V to 600 V |
Key Features
- ±0.3% DC V basic accuracy, wide 40 Hz to 1 kHz AC V frequency characteristics
- Measure up to 10 A with direct input
- Dual display lets you check voltage and frequency simultaneously
- Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)
- USB communications function supports PC measurements (optional)
- Broad -25°C to 65°C (-13°F to 149°F) operating temperature range
Product Description
The Hioki DT4200 Digital Multimeter Series consists of a complete lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super-fast response rate and safety features that enhance electrical testing. The DT4256 is a digital multimeter designed to deliver maximum functionality for use in a wide range of settings.
Available on EnvMart, these Multimeters are designed for accurate measurement of voltage, current, and resistance in electrical circuits. Hioki Multimeters offer high precision and reliability, making them essential for electrical testing, diagnostics, and maintenance applications.
