Hioki Digital Multimeter DT4253
Specifications
| Country of Origin | Japan |
|---|---|
| DC Voltage Range | 600.0 mV to 1000 V / ±0.3 % rdg. ±5 dgt. |
| AC Voltage Range | 6.000 V to 1000 V / 40 Hz - 1 kHz / ±0.9 % rdg. ±3 dgt. (True RMS) |
| Capacitance Range | 1.000 μF to 10.00 mF / ±1.9 % rdg. ±5 dgt. |
| Resistance Range | 600.0 Ω to 60.00 MΩ / ±0.7 % rdg. ±5 dgt. |
| Display | 4-digit LCD / bar graph |
| Frequency range | 99.99 Hz to 99.99 kHz / ±0.1 % rdg. ±1 dgt. |
| Diode Test | ≤5.0 V open terminal voltage / ≤0.5 mA test current |
| Brand | HIOKI |
| Power Supply | 4× LR03 batteries / 130h use (backlight OFF) |
| Dimensions | 84 × 174 × 52 mm |
| Model | DT4253 |
| Accessories | Test lead L9207-10 / Holster / Manual / 4× LR03 batteries |
| Weight | 390 g (with batteries & holster) |
| Functions | Filter / hold / MAX/MIN/AVG / relative display / auto-power save / USB (optional) / 4-20mA conversion |
| DC Current range | 60.00 μA to 60.00 mA / ±0.8 % rdg. ±5 dgt. |
| Continuity Check | ≤25 Ω (buzzer) / Response time - ≥0.5 ms |
| AUTO AC/DC Voltage (V) | Yes |
| 4-20mA Percentage Display | Yes |
| AC Current Range (Clamp Probe) | 10.00 A to 1000 A / ±0.9 % rdg. ±3 dgt. (True RMS) |
| Temperature (K-Type) | -40.0 to 400.0 °C / ±0.5 % rdg. ±2 °C |
Key Features
- Ideal for measuring currents ranging from instrumentation signals (4 to 20 mA) to flame currents (μA) with built in high-sensitivity current ranges (DT4253)
- Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)
- Dual display lets you check voltage and frequency simultaneously
Product Description
The Hioki DT4200 Digital Multimeter Series consists of a complete lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super-fast response rate and safety features that enhance electrical testing. The DT4253 is a digital multimeter designed specifically for HVAC testing, with ±0.5% DC V accuracy, temperature and clamp sensor testing, and a wide 40 Hz to 1 kHz bandwidth.
Available on EnvMart, these Multimeters are designed for accurate measurement of voltage, current, and resistance in electrical circuits. Hioki Multimeters offer high precision and reliability, making them essential for electrical testing, diagnostics, and maintenance applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The DC voltage measurement range is from 600.0 mV to 1000 V with an accuracy of ±0.3 % reading ±5 digits.
The AC voltage range is from 6.000 V to 1000 V, with a frequency range of 40 Hz to 1 kHz and an accuracy of ±0.9 % reading ±3 digits (True RMS).
This model can measure resistance up to 60.00 MΩ with an accuracy of ±0.7 % reading ±5 digits.
The capacitance range is from 1.000 μF to 10.00 mF, with an accuracy of ±1.9 % reading ±5 digits.
The Hioki DT4253 measures 84 × 174 × 52 mm and weighs 390 g including batteries and holster.
It is powered by 4 LR03 batteries, providing approximately 130 hours of use with the backlight turned off.
Yes, it can measure temperature using K-Type thermocouples in the range of -40.0 to 400.0 °C with an accuracy of ±0.5 % reading ±2 °C.
Included accessories are a test lead (L9207-10), a holster, a manual, and 4 LR03 batteries.
The frequency measurement range is from 99.99 Hz to 99.99 kHz with an accuracy of ±0.1 % reading ±1 digit.
Yes, it can perform a continuity check with a threshold of ≤25 Ω and a response time of ≥0.5 ms, accompanied by a buzzer.
It supports various functions including filter, hold, MAX/MIN/AVG, relative display, auto-power save, and optional USB for 4-20mA conversion.
The diode test has an open terminal voltage of ≤5.0 V and a test current of ≤0.5 mA.
