Eaton 25A Bolted Tag Fuse F2 550V ac ESD25

Name: Eaton 25A Bolted Tag Fuse F2 550V ac ESD25
Brand: Eaton
SKU: 421003
Price: 20.22 USD
Availability: InStock



Category Tag Fuse Brand Eaton Condition New

Specifications

Country of Origin	India
Voltage	550V ac
Diameter	13.8mm
Brand	Eaton
Height	14mm
Length	35.5mm
Model	ESD25
Width	14mm
Overall Length	68mm
Current Rating	25A
Series	ESD
Standards/Approvals	RoHS, IEC 60269-2, CE
Fuse Size	F2
Tag Width	15mm
Tag Orientation	Offset

Key Features

Current rating of 25A providing reliable circuit protection.
Fuse size is F2 with a fuse speed of F for high rupturing capacity.
Offset tag orientation with a tag width of 15mm for secure installation.
Compact dimensions with overall length 68mm and diameter 13.8mm.
Complies with RoHS, IEC 60269-2, and CE standards ensuring quality and safety.
Series ESD fuse link suitable for multiple industrial environments.
Manufactured in India ensuring local quality compliance.

Product Description

Eaton ESD25 Bolted Tag Fuse 25A F2 550V ac is a specialized fuse link designed for industrial applications requiring reliable power distribution and cable protection at low voltages.

This bolted tag fuse features a 25-amp current rating and operates at 550 volts AC, making it suitable for general industrial circuits and electrical protection systems. The fuse is size F2 with a fuse speed rating of F, ensuring fast and effective response to current surges. It is designed with an offset tag orientation and a 15 mm wide tag for secure and efficient mounting in fuse blocks or holders.

The fuse dimensions include a 35.5 mm length of the element itself, an overall length of 68 mm, a diameter of 13.8 mm, a height of 14 mm, and a 14 mm width, offering a compact form factor for integration in constrained electrical panels.

Compliant with RoHS, IEC 60269-2, and CE standards, this fuse link guarantees a high rupture capacity and excellent peak let-through current limitation to protect sensitive equipment and maintain system safety. Eaton’s ESD series is well-known for selective coordination, providing a selective ratio of 1:1:6 between minor and major fuses, making it ideal for layered protection architectures.

Manufactured in India, this Eaton fuse benefits from stringent quality processes and is a suitable choice for industrial, manufacturing, electrical distribution, and HVAC electrical safety applications.

Current rating of 25A providing reliable circuit protection. Fuse size is F2 with a fuse speed of F for high rupturing capacity. Voltage rating of 550V AC suitable for low-voltage systems. Offset tag orientation with a tag width of 15mm for secure installation.

Compact dimensions with overall length 68mm and diameter 13.8mm. Complies with RoHS, IEC 60269-2, and CE standards ensuring quality and safety. Series ESD fuse link suitable for multiple industrial environments. Manufactured in India ensuring local quality compliance.
