KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD3-120B
Specifications
| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Length | 27mm |
| Model | OHD3-120B |
| Depth | 12.5mm |
| Width | 13.5mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | OHD Thermal Guard |
| Maximum Switching Current | 300mA |
| Maximum Operating Temperature | 150°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Tab Leads |
| Contact Resistance | 150mΩ |
| Maximum Switching Power | 6W |
| Standards/Approvals | CSA, RoHS, TUV, UL |
| Maximum Switching Voltage | 110V ac/dc |
Key Features
- Configured as SPST for single-pole single-throw switching.
- Supports maximum switching current of 300 mA and power of 6 W.
- Maximum switching voltage rating is 110 V ac/dc for versatile use.
- Contact resistance is low at 150 milliohms ensuring efficient operation.
- Constructed with nickel iron alloy contact material for durability.
- Features tab lead terminals suitable for through hole mounting.
- Operates reliably between -20°C and 150°C temperature range.
- Compact dimensions of 27 mm length, 13.5 mm width, and 12.5 mm depth.
Product Description
KEMET OHD3-120B SPST Through Hole Reed Switch is designed for reliable switching operations in electrical and automation applications. It supports a maximum switching current of 300 mA and a maximum voltage of 110 V ac/dc, making it suitable for a range of low power switching tasks.
This reed switch features a nickel iron alloy contact material that ensures excellent durability and low contact resistance of 150 milliohms, which supports efficient signal transmission. The tab lead terminal and through hole mount type enable straightforward and secure PCB integration.
Operating across a wide temperature range from -20°C to 150°C, the switch is ideal for use in environments that require thermal resilience. Its compact physical dimensions (27 mm length, 13.5 mm width, and 12.5 mm depth) allow it to be used in space-constrained circuits.
The OHD Thermal Guard series to which this model belongs is well-known for its high reliability, high-speed response, and environmental durability, making it a suitable choice for industrial, instrumentation, and control systems.
Configured as SPST for single-pole single-throw switching. Maximum switching current of 300 mA and power of 6 W. Maximum switching voltage of 110 V ac/dc for versatile use. Low contact resistance of 150 milliohms for efficient operation.
Nickel iron alloy contact material provides excellent durability. Tab lead terminals simplify through hole mounting on PCBs. Wide operating temperature range from -20°C to 150°C. Compact dimensions for ease of installation in tight spaces.
Certified with CSA, RoHS, TUV, and UL standards.
This Reed Switch is widely applicable in electrical circuits requiring reliable switching functions such as sensors, telecommunications, industrial controls, and automation systems. Its robust design and certifications ensure it meets demanding industry standards.
Explore EnvMart's wide range of switches and automation components to find compatible products and accessories that suit your project requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for this model is 300 mA.
This reed switch has a maximum switching voltage rating of 110 V ac/dc.
It features tab lead terminals suitable for through hole mounting on PCBs.
The contact resistance is low at 150 milliohms, ensuring efficient operation.
The dimensions of this model are 27 mm in length, 13.5 mm in width, and 12.5 mm in depth.
It operates reliably between -20°C and 150°C.
The contact material is made of nickel iron alloy, providing durability.
It is certified with CSA, RoHS, TUV, and UL standards.
This switch is applicable in electrical circuits requiring reliable switching functions such as sensors, telecommunications, industrial controls, and automation systems.
The maximum switching power is 6 W.
This model belongs to the OHD Thermal Guard series, known for high reliability and environmental durability.
It is configured as SPST for single-pole single-throw switching.
