Eaton 80A Bolted Tag Fuse B1 660 V ac, 350V dc High Rupture Capacity 111 mm TC80

Eaton TC80 is an 80 Amp bolted tag fuse designed for robust electrical circuit protection in industrial and commercial low voltage applications. It supports a voltage rating of 660 V AC and 350 V DC, enabling use across diverse electrical systems requiring reliable fuse operation. This fuse comes equipped with a centred bolted tag offering a secure electrical connection and high rupture capacity capable of interrupting fault currents up to 80kA safely.

The TC80 fuse's conformance to BS 88 and IEC 60269 standards guarantees its safety and efficacy in meeting specific industrial electrical regulations. Installed easily with fixing centres of 111 mm, it features a B1 size with compact overall dimensions for space-efficient integration into panels and fuse holders.

Designed for general industrial and commercial electrical protection needs, Eaton's TC80 fuse is ideal for deployment in control panels, safety circuits, and various installations requiring high-performance fusing solutions. Its compatibility with Eaton's RS200 fuse holders and classification in the gL/gG fuse category ensures optimal protection against overloads and short circuits, safeguarding connected equipment and wiring.

Rated current capacity of 80A ensures effective conduction under normal operation. Supports dual voltage ratings of 660 V AC and 350 V DC for versatile electrical configurations. Constructed with a centred bolted tag for stable and secure electrical connections.

High rupture capacity design guarantees safe interruption of high fault currents up to 80kA. Complies with BS 88 and IEC 60269 safety standards for low voltage electrical applications. Fuse size B1 with precise fixing centres at 111 mm for easy installation compatibility.

Compact dimensions: length 58 mm, overall length 136.5 mm, diameter and width at 26 mm. Designed for general industrial use in circuit protection and electrical safety systems. Compatible with Eaton RS200 fuse holder and suitable for gL/gG fuse categories to optimize cable and equipment protection.

This Eaton bolted Tag Fuse is manufactured in Hungary, ensuring quality and adherence to rigorous industrial standards. It is widely used in industrial electrical safety circuits, offering dependable performance against power surges and fault currents. Eaton's TC80 fuse is critical for maintaining circuit integrity and protecting expensive equipment and infrastructure in a variety of industrial settings.
