Littelfuse Thyristor SCR 800 V Repetitive Peak Reverse Voltage, 10 A Rated Average On-State Current, 60 mA Maximum 2N6405G
Specifications
| Country of Origin | India |
|---|---|
| Brand | Littelfuse |
| Model | 2N6405G |
| Mount Type | Through Hole |
| Series | 2N640x |
| Maximum Operating Temperature | 125°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Rated Average On-State Current Irms | 10A |
| Thyristor Type | SCR |
| Repetitive Peak Reverse Voltage VDRM | 800V |
| Surge Current Rating | 160A |
| Maximum Gate Trigger Current Igt | 60mA |
| Maximum Holding Current Ih | 60mA |
| Maximum Gate Trigger Voltage Vgt | 2.5V |
| Peak On-State Voltage | 1.7V |
| Repetitive Peak Off-State Current | 2mA |
Key Features
- Features a TO-220 package suitable for through-hole mounting.
- Supports a maximum surge current rating of 160 A for enhanced durability under transient conditions.
- Operates between -40°C and 125°C, suitable for harsh environments.
- Has a maximum gate trigger current of 60 mA and holding current of 60 mA.
- Maintains a peak on-state voltage of 1.7 V, ensuring efficient conduction.
- Designed for phase control applications as a solid-state switch.
- Equipped with 3 pins and a repetitive peak off-state current of 2 mA.
- Meets no specific automotive or approval standards, focusing on general industrial use.
Product Description
Littelfuse 2N6405G Thyristor SCR offers reliable switching capabilities with a repetitive peak reverse voltage of 800 V and rated average on-state current of 10 A. It comes packaged in a TO-220 case, enabling straightforward through-hole mounting on circuit boards.
This Thyristor is engineered to handle surge currents up to 160 A, making it suitable for applications requiring high transient current capability. It operates effectively within a wide temperature range from -40°C to 125°C, ensuring performance stability in varied industrial environments.
The device features a maximum gate trigger current of 60 mA and a holding current of 60 mA, allowing precise control triggering and stable conduction. Its peak on-state voltage is 1.7 V, which ensures low power losses during operation.
With 3 pins and standard SCR construction, the 2N6405G is ideal for use in phase control circuits and other power electronics applications. It is not specifically certified for automotive use and lacks formal approvals, focusing instead on versatile industrial and electronic component use cases.
This component supports through-hole mount assembly, making it compatible with a wide range of electrical and electronic engineering projects. Typical industrial uses include power regulation, controlled rectification, and switching in HVAC, manufacturing, and instrumentation systems.
Features a TO-220 package suitable for through-hole mounting. Supports a maximum surge current rating of 160 A for enhanced durability under transient conditions. Operates between -40°C and 125°C, suitable for harsh environments.
Has a maximum gate trigger current of 60 mA and holding current of 60 mA. Maintains a peak on-state voltage of 1.7 V, ensuring efficient conduction. Designed for phase control applications as a solid-state switch. Equipped with 3 pins and a repetitive peak off-state current of 2 mA.
Meets no specific automotive or approval standards, focusing on general industrial use. Explore Littelfuse products and related semiconductor components at EnvMart for your industrial and electronic design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 125°C.
This Thyristor has a rated average on-state current of 10 A.
It supports a maximum surge current rating of 160 A.
The repetitive peak reverse voltage is 800 V.
This model supports through-hole mounting and comes in a TO-220 package.
The peak on-state voltage is maintained at 1.7 V.
The maximum gate trigger current is 60 mA.
The minimum operating temperature is -40°C.
This model is equipped with 3 pins.
The holding current for this Thyristor is 60 mA.
It is designed for phase control applications as a solid-state switch.
The repetitive peak off-state current is 2 mA.
