Icel PMB Polypropylene Capacitor, ±10 % Tolerance, 390 nF Capacitance, 1.2 kV DC, 500V AC Rated Voltage PMB2123390KSPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Icel |
| Height | 28mm |
| Length | 43mm |
| Model | PMB2123390KSPB |
| Packaging | Tape & Reel |
| Width | 25mm |
| Mount Type | Screw |
| Series | PMB |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±10 % |
| Capacitance | 390nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder Lug |
| Dissipation Factor | 0.0005% |
| Lead Length | 17.2mm |
| Standards/Approvals | RoHS |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 500V ac |
| Rated DC Voltage | 1.2kV dc |
| Automotive Standard | AEC-Q200 |
| Equivalent Series Resistance ESR | 4.6mΩ |
Key Features
- This capacitor supports a rated DC voltage of 1.2 kV and AC voltage of 500V.
- It features a screw mount type with solder lug terminals for secure connections.
- Designed with a plastic package case ensuring electrical insulation and durability.
- Ideal for use in SMPS and snubber circuits as well as resonant and power semiconductor applications.
- Operates effectively within a temperature range from -40°C to +85°C.
- Complies with RoHS standards and automotive AEC-Q200 for quality assurance.
- Compact dimensions of 43 mm length, 28 mm height, and 25 mm width facilitate easy integration.
Product Description
The Icel PMB2123390KSPB polypropylene capacitor is engineered for use in demanding electronic environments requiring high voltage and precision. With a capacitance of 390 nF and a tolerance of ±10 %, it ensures reliable performance in power conversion and control circuits. This film capacitor is rated for 1.2 kV DC and 500V AC voltage, making it suitable for use in power semiconductor protection circuits including IGBT modules and SMPS applications.
Featuring a screw mount design and solder lug terminals with a lead length of 17.2 mm, installation is secure and reliable. The plastic package case provides excellent insulation and mechanical protection, supporting operation in industrial and automotive environments.
Icel’s PMB series capacitor offers exceptional thermal stability with operational temperatures ranging from -40°C to +85°C. Its low equivalent series resistance (ESR) of 4.6 milliohms and minimal dissipation factor of 0.0005% contribute to efficient energy performance and reduced losses.
Dimensions are optimized for compact circuits, measuring 43 mm in length, 28 mm in height, and 25 mm in width. The component complies fully with RoHS directives and meets automotive standard AEC-Q200 ensuring quality and safety for automotive electronics.
390 nF capacitance with ±10 % tolerance. Rated 1.2 kV DC and 500V AC voltage. Screw mount with solder lug terminals. Plastic package case for insulation and durability. Thermal range from -40°C to +85°C. Low ESR of 4.6 mΩ and dissipation factor of 0.0005%.
Compliance with RoHS and AEC-Q200 standards. Compact dimensions: 43mm x 25mm x 28mm.
This capacitor is ideal for industrial, automotive, and commercial applications including power supply units, snubber circuits, and IGBT module protection. Its robust design ensures stable operation in high voltage, high current, and high pulse environments.
Explore more high-quality film capacitors in the electronics components category at EnvMart for your advanced circuit design requirements.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Icel PMB2123390KSPB has a capacitance of 390 nF with a tolerance of ±10%.
It is rated for a DC voltage of 1.2 kV and an AC voltage of 500V.
This capacitor operates effectively within a temperature range of -40°C to +85°C.
The capacitor features a screw mount design with solder lug terminals for secure connections.
The dimensions are 43 mm in length, 28 mm in height, and 25 mm in width.
The equivalent series resistance (ESR) is 4.6 milliohms.
The dissipation factor is 0.0005%.
Yes, it complies with RoHS standards and the automotive AEC-Q200 standard.
It is suitable for use in SMPS, snubber circuits, and power semiconductor applications including IGBT modules.
The lead length for the solder lug terminals is 17.2 mm.
The capacitor features a plastic package case, providing electrical insulation and mechanical protection.
The country of origin for this capacitor is India.
