TE Connectivity 1812 Shielded Surface Mount Inductor with Ferrite Core 680nH ±20% 500mA Idc Q40 3613CR68M
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TE Connectivity |
| Height | 3.2mm |
| Length | 4.5mm |
| Model | 3613CR68M |
| Depth | 3.2mm |
| Packaging | Tape |
| Series | 3613C |
| Maximum Operating Temperature | 100°C |
| Minimum Operating Temperature | -30°C |
| Core Material | Ferrite |
| Inductance | 680nH |
| Standards/Approvals | RoHS |
| Package/Case | 1812 |
| Maximum DC Current | 500mA |
| Pin Count | 2 |
| Maximum DC Resistance | 400mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 135MHz |
| Minimum Quality Factor | 40 |
| Inductor Construction | Moulded |
Key Features
- Compact 1812 package size measures 4.5mm length by 3.2mm height and depth.
- Ferrite core offers high reliability and excellent shielding for noise reduction.
- Operational temperature range from -30°C to 100°C.
- Supports automatic mounting with solder termination style.
- Maximum DC resistance of 400mΩ ensures efficient current flow.
- Moulded wire-wound construction with a minimum quality factor of 40 for stable performance.
- Maximum self-resonant frequency up to 135MHz supports high-frequency applications.
- RoHS compliant with tape packaging for surface mount assembly.
Product Description
TE Connectivity model 3613CR68M is an 1812 size shielded surface mount inductor designed with a ferrite core and moulded wire-wound construction. It provides a precise 680nH inductance with ±20% tolerance to meet demanding circuit specifications. The device operates reliably in temperatures ranging from -30°C to 100°C, making it suitable for various industrial, commercial, and consumer electronics applications.
Its compact dimensions of 4.5mm length and 3.2mm height and depth enable efficient use of PCB space. The inductor has a maximum DC current rating of 500mA and maximum DC resistance of 400mΩ, ensuring low power loss and heat generation. The solder termination style facilitates automated surface mount assembly on PCBs, speeding up production workflows.
The ferrite core material and full shielding effectively reduce electromagnetic interference, improving circuit stability. This component is moulded for durability, has a minimum quality factor of 40, and a maximum self-resonant frequency of 135MHz, making it ideal for high-frequency signal filtering and power management circuits.
Packaged on tape, the 3613CR68M inductor supports automated pick-and-place processes commonly used in electronic manufacturing. It is RoHS compliant, meeting environmental standards.
Compact 1812 size for space-efficient PCBs. Reliable ferrite core construction with shielding. High-frequency capability with 135MHz resonance. Wide operational temperature range from -30°C to +100°C. Low DC resistance improves power efficiency.
Easy solder termination for surface mount technology (SMT). Quality factor of at least 40 ensures performance stability. Tape packaging suited for automatic assembly. RoHS compliant and environmentally safe.
This TE Connectivity surface mount inductor is ideal for electronic components, power management, signal filtering, and noise reduction applications in industrial and consumer electronics. Explore more surface mount inductors and electronic components in EnvMart's Electronics & Electricals category.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 680nH with a tolerance of ±20%.
This inductor has a maximum DC current rating of 500mA.
The dimensions of this unit are 4.5mm in length, and 3.2mm in both height and depth.
The maximum operating temperature for this model is 100°C.
This inductor uses a ferrite core material, which provides high reliability and excellent shielding.
The minimum quality factor of this model is 40, ensuring stable performance.
The maximum self-resonant frequency is up to 135MHz, making it suitable for high-frequency applications.
The termination style of this inductor is solder, facilitating automated surface mount assembly.
Yes, this model is RoHS compliant, meeting environmental standards.
The maximum DC resistance is 400mΩ, which helps ensure efficient current flow.
This inductor is packaged on tape, which is suitable for automated pick-and-place processes in manufacturing.
This inductor is suitable for power management, signal filtering, and noise reduction applications in various electronic devices.
