TDK Surface Mount Common Mode Line Filter with Ferrite Core 400mA Idc, 2.5mm x 1.2mm x 2mm ACM2520-301-2P-T

TDK ACM2520-301-2P-T is a surface mount common mode line filter designed for effective suppression of electromagnetic interference (EMI) and noise in electronic circuits. Featuring a ferrite core and wirewound inductor construction, it offers high common-mode impedance greater than 1000Ω at 100MHz, while maintaining low differential mode impedance, which minimizes impact on high-speed signal transmission.

With a rated maximum DC current of 400mA and maximum DC resistance of 350mΩ, this compact 2520 package (2.5mm length, 1.2mm height, 2mm depth) component supports reliable performance in temperatures ranging from -25°C to 85°C. Its 3-pin design integrates seamlessly into PCB layouts requiring space optimization, such as USB and IEEE1394 computer lines, and LVDS panel link lines.

The product is RoHS compliant, reflecting TDK's commitment to environmentally safe manufacturing. The ACM Series is widely applied in electronic devices to reduce radiation and suppress common-mode noise, improving device reliability and signal integrity in industrial, laboratory, and commercial electronics applications.

The filter features a Ferrite Core and wirewound inductor construction for effective common-mode noise suppression. Low maximum DC resistance (350mΩ) reduces power loss and heat generation. Compact size (2520 package) enables dense PCB assembly.

Operating temperature range of -25°C to 85°C suits various industrial environments. Ideal for USB, IEEE1394, LVDS panel link lines filtering applications. Ensures high common-mode impedance (>1000Ω@100MHz) for EMI noise attenuation.

The ACM2520-301-2P-T filter is designed to enhance electronic device performance across multiple sectors including industrial controls, telecommunications, computing hardware, and other precision electronic equipment. EnvMart offers this product as part of its extensive range of high-quality electronic components.
