Siemens Inverter Drive 5.5 kW 3 Phase SINAMICS G115D Series 480V 26.4A 6SL3520-2XB05-5AB0

Siemens 6SL3520-2XB05-5AB0 Inverter Drive is a 5.5 kW, 3 phase converter, part of the SINAMICS G115D series designed for efficient industrial motor control applications. Operating at a voltage range of 380 V to 480 V and a maximum output current of 26.4 A, this drive supports asynchronous motors with efficiency class IE3 and synchronous reluctance motors with IE4 for maximum energy efficiency.

This wall-mount inverter drive is constructed with an IP66 and IP65 rated enclosure, offering excellent protection against dust and water ingress, making it suitable for harsh industrial environments. It can operate reliably within a broad temperature range from -30°C to 55°C, allowing deployment in diverse climate conditions.

The SINAMICS G115D series inverter is aimed primarily at horizontal conveyor system applications, providing everything from simple speed control to advanced encoderless vector control, enhancing operational flexibility. Its modular design supports quick installation, easy cabling, and minimal cooling requirements without the need for a control cabinet.

Integrated safety features include a Safe Torque Off (STO) function with fail safe digital inputs or PROFIsafe compatibility, ensuring safe operations in industrial settings. The compact form factor, with dimensions of 425 mm width, 180 mm length, and 169 mm depth, facilitates installation in space-constrained environments.

It is a certified product meeting several international standards such as UL, SEMI F47, REACH, CE, C-Tick (RCM), cUL, EAC, and KCC, reflecting its compliance with global safety and environmental requirements.

Designed for use with AC motors including SIMOGEAR 2KJ8 geared motors. Supports asynchronous motors IE3 and synchronous reluctance motors IE4 efficiency classes. Wall mount type enclosure with IP66 and IP65 ratings. Operating temperature range from -30°C to 55°C.

Maximum output current 26.4 A and output frequency up to 550 Hz. Multiple international standards certifications. Integrated safety functions with STO and fail safe inputs. Compact dimensions enable installation flexibility.

Energy efficient Better World product, ideal for conveyor systems.

This Siemens inverter drive is well suited for industrial automation, manufacturing, material handling, conveyor systems, and HVAC applications requiring precise motor control and energy savings. It supports reliable operation with reduced space and installation effort while maintaining safety standards.
