Mersen 20A Bolted Tag Fuse A2 690V AC 73 mm Q1019259 / BTIA69V20M25
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 690V ac |
| Diameter | 21.9mm |
| Brand | Mersen |
| Height | 56.5mm |
| Length | 54.5mm |
| Model | Q1019259 / BTIA69V20M25 |
| Width | 21mm |
| Overall Length | 86mm |
| Current Rating | 20A |
| Series | Offset Tag fuse-links gM 690VAC/460VDC |
| Standards/Approvals | RoHS, IEC 60269, REACH, BS 88, EN 60269-2, CE |
| Fuse Size | A2 |
| Fixing Centres | 73 mm |
| Tag Width | 9.2mm |
| Tag Orientation | Offset |
| Application Category | gM |
Key Features
- Rated current is 20 amperes for reliable circuit protection.
- Designed with A2 fuse size suitable for specific fuseholder dimensions.
- Fuse speed category labeled as high (F) for fast-acting protection.
- Features an offset tag orientation with 9.2 mm tag width for secure mounting.
- Constructed for motor protection (gM type) and general purpose use.
- Overall length measures 86 mm and diameter is 21.9 mm.
- Certified to comply with IEC 60269, BS 88, EN 60269-2, RoHS, REACH, and CE standards.
- Manufactured in India ensuring quality and compliance.
Product Description
Mersen Q1019259 / BTIA69V20M25 20A Bolted Tag Fuse A2 is designed for reliable protection in electrical circuits, rated at 690V AC and 20 amperes current. It is specifically engineered to provide high current limitation in applications requiring fast-acting fuse protection.
This bolted tag fuse has fixing centres measuring 73 mm, with an offset tag orientation and tag width of 9.2 mm, facilitating easy installation in fuseholders or direct bolting onto busbars and disconnectors.
The fuse dimensions include a length of 54.5 mm, overall length of 86 mm, height of 56.5 mm, width of 21 mm, and diameter of 21.9 mm. It belongs to the 'Offset Tag fuse-links gM 690VAC/460VDC' series, ensuring compatibility in relevant electrical installations.
The device is suitable for motor protection (gM type) as well as general purpose applications, offering excellent current limitation for overload conditions and preventing the possibility of exchange with higher rated fuses in its range.
Certified according to stringent standards including IEC 60269, BS 88, EN 60269-2, RoHS, REACH, and CE, this fuse complies with international safety and environmental regulations. It is manufactured in India ensuring quality production standards.
Rated current is 20 amperes for reliable circuit protection. Designed with A2 fuse size suitable for specific fuseholder dimensions. Fuse speed category labeled as high (F) for fast-acting protection. Features an offset tag orientation with 9.2 mm tag width for secure mounting.
Constructed for motor protection (gM type) and general purpose use. Overall length measures 86 mm and diameter is 21.9 mm. Certified to comply with IEC 60269, BS 88, EN 60269-2, RoHS, REACH, and CE standards. Manufactured in India ensuring quality and compliance.
This Mersen tag fuse is ideal for industrial, commercial, and electrical applications requiring robust fuse protection. It is compatible with fuseholders, busbars, and fuse interruptors, making it versatile for maintenance and new installations.
Explore more from the extensive range of Tag Fuses at EnvMart to find the appropriate fuse solutions for your electrical protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated current of this bolted tag fuse is 20 amperes, providing reliable circuit protection.
This fuse is rated for operation at 690V AC.
The overall length of this model is 86 mm, with a diameter of 21.9 mm, a height of 56.5 mm, and a width of 21 mm.
The fuse size is A2, and it is categorized as a gM type, suitable for motor protection and general purpose use.
This model features an offset tag orientation with a tag width of 9.2 mm, facilitating secure mounting.
It is certified to comply with IEC 60269, BS 88, EN 60269-2, RoHS, REACH, and CE standards.
Yes, it is designed for motor protection (gM type) as well as general purpose applications, providing excellent current limitation.
This bolted tag fuse is manufactured in India, ensuring compliance with quality production standards.
The fuse speed category is labeled as high (F), indicating fast-acting protection for electrical circuits.
The overall length of this fuse is 86 mm, which is important for compatibility with installation requirements.
This fuse provides reliable circuit protection and high current limitation, preventing overload conditions in electrical circuits.
