Schneider Electric TeSys GV Thermal Circuit Breaker 80A Current Rating 3-Pole DIN Rail GV4PE80B
Specifications
| Country of Origin | Poland |
|---|---|
| Range | TeSys |
| Brand | Schneider Electric |
| Height | 155mm |
| Model | GV4PE80B |
| Depth | 155mm |
| Width | 116mm |
| Mount Type | DIN Rail |
| Current Rating | 80A |
| Series | TeSyS GV |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 3 |
| Standards/Approvals | CSA, REACH, IEC, EU-RO MR, UL, EAC, CCC, ATEX, RoHS, MR, EN |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Thermomagnetic |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| b Magnetic GV4L | to be used with an overload relay or a drive |
| b Thermal magnetic GV4P | electronic protection with wide range setting, dual class (10 & 20) |
| b Multifunction motor protection GV4PEM | GV4P with adjustable advanced protections and possibility to have |
Key Features
- This device provides thermal magnetic protection for 3-phase motors rated 22-37kW @ 400V.
- Adjustable thermal protection with setting current range 40-80A and selectable tripping class 10 or 20.
- Includes magnetic protection trip at 17 times the nominal current for short circuit safety.
- Features start-stop toggle switch control and screw type Everlink BTR terminals for secure connection.
- Breaking capacity of 10kA rated AC voltage of 690V with multi-standard certifications including IEC, UL, CSA, and RoHS compliant.
- Additional protections include phase unbalance, short time delay, loss protection, and ground fault detection.
- Compact build with dimensions approx. 155mm height, 155mm depth, and 116mm width for easy DIN rail installation.
Product Description
Schneider Electric GV4PE80B is a 3-pole thermal circuit breaker tailored for protection of 3-phase motors in industrial and commercial electrical automation applications. Rated for a current of 80A and a breaking capacity of 10kA at 690V AC, it enables reliable motor protection while conforming to rigorous international standards such as IEC, UL, CSA, CCC, EAC, and ATEX.
This thermal magnetic circuit breaker offers adjustable thermal protection via dial settings in the range 40-80A with selectable tripping classes 10 and 20, along with magnetic trip protection at 17 times nominal current, providing quick response to short circuits. Additional advanced motor protections include short time delay stage at 13 times Ir, phase unbalance and loss protections, and ground fault detection.
Control is facilitated by a toggle switch as a reset actuator, with connections enabled through Everlink BTR screw terminals ensuring secure and efficient wiring. The breaker dimensions are 155mm height, 155mm depth, and 116mm width, optimized for easy DIN rail mounting.
The product is designed for use with motor applications rated 22-37 kW @ 400V, suitable for manufacturing, industrial automation, HVAC systems, and commercial motor protection.
Schneider Electric’s GV4PE80B multifunction motor protection provides additional flexibility with internal locations for auxiliary contact blocks and voltage trip units, catering to customized operational requirements in diverse environments.
This product suits industrial, manufacturing, and commercial settings requiring robust motor protection. Adjustable thermal settings enhance operational safety and motor lifespan. High breaking capacity ensures secure interruption under fault conditions.
Compliance with multiple global standards guarantees quality and reliability. Compact size allows integration within standard DIN rail setups. Explore the full range of Schneider Electric products and Thermal Circuit Breakers at EnvMart for trusted industrial electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this thermal circuit breaker is 80A.
It has a breaking capacity of 10kA at a rated AC voltage of 690V.
The dimensions are approximately 155mm in height, 155mm in depth, and 116mm in width.
This model is designed for DIN rail mounting.
It features thermomagnetic tripping characteristics with selectable classes 10 and 20.
It uses a toggle switch as the reset actuator type.
It includes protections against phase unbalance, short time delay, loss protection, and ground fault detection.
The rated AC voltage for this device is 690V.
It complies with multiple standards including CSA, IEC, UL, EAC, CCC, and RoHS.
The adjustable thermal protection has a setting current range from 40A to 80A.
It features screw type Everlink BTR terminals for secure connection.
It is suitable for motor applications rated 22-37 kW at 400V, commonly used in industrial and commercial settings.
