Bourns Shielded Wirewound Surface Mount Inductor 220 μH ±20% 200 mA IDC Ferrite Core SRN4026
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.5mm |
| Length | 4mm |
| Model | SRN4026 |
| Depth | 4mm |
| Packaging | Reel |
| Series | SRN4026 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance Range | 1 to 220 μH |
| Inductance | 220μH |
| Standards/Approvals | RoHS |
| Package/Case | 4026 |
| Maximum DC Current | 200mA |
| Pin Count | 2 |
| Maximum DC Resistance | 2.76Ω |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 4MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a ferrite core for efficient magnetic performance.
- Inductance tolerance of ±20% ensures consistent quality.
- Supports up to 200 mA maximum DC current for reliable operation.
- Compact 4026 package size with dimensions 4 mm length, 2.5 mm height, and 4 mm depth.
- Includes shielding and complies with AEC-Q200 automotive standards.
- Operating temperature range from -40°C to 125°C for harsh environments.
- Maximum DC resistance is 2.76 ohms and minimum quality factor is 30.
- Moulded wirewound construction provides durability and precision.
Product Description
Bourns SRN4026 shielded wirewound surface mount inductor provides 220 μH inductance with ±20% tolerance, designed for efficient power management in electronic circuits. Featuring a ferrite core and semi-magnetically shielded construction, this compact inductor fits a 4026 package size (4 mm length, 2.5 mm height, and 4 mm depth) suitable for surface mounting.
It supports a maximum DC current of 200 mA and operates reliably between -40°C and 125°C, making it suitable for automotive and industrial applications compliant with AEC-Q200 standards. The device exhibits a maximum DC resistance of 2.76 ohms and a minimum quality factor of 30, ensuring stable filtering and power delivery.
This inductor's moulded wirewound design and solder termination style facilitate easy PCB mounting and long-term durability. Its shielding minimizes electromagnetic interference, enhancing performance in sensitive electronic devices.
Common uses include integration within DC/DC converters, notebook computers, digital video cameras, hard disk drives, cellphones, televisions, and LCD displays. This makes it a versatile component for electronics, industrial, automotive, and consumer applications.
Features a ferrite core for efficient magnetic performance. Inductance tolerance of ±20% ensures consistent quality. Supports up to 200 mA maximum DC current for reliable operation. Compact 4026 package size with dimensions 4 mm length, 2.5 mm height, and 4 mm depth.
Includes shielding and complies with AEC-Q200 automotive standards. Operating temperature range from -40°C to 125°C for harsh environments. Maximum DC resistance is 2.76 ohms and minimum quality factor is 30. Moulded wirewound construction provides durability and precision.
Termination style is solder, suitable for surface mount PCB applications. Commonly used in DC/DC converters, notebook computers, video cameras, HDDs, cellphones, televisions, and LCD displays. Discover Bourns inductors and other electronic components on EnvMart for reliable circuit design and manufacturing.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Bourns SRN4026 inductor has an inductance value of 220 μH with an inductance tolerance of ±20%.
This model supports a maximum DC current of 200 mA, ensuring reliable operation in electronic circuits.
The dimensions of the SRN4026 inductor are 4 mm in length, 2.5 mm in height, and 4 mm in depth, fitting a compact 4026 package size.
The SRN4026 inductor features a ferrite core, which contributes to its efficient magnetic performance.
The maximum DC resistance of the SRN4026 inductor is 2.76 ohms, which is important for ensuring stable performance.
This inductor has a minimum quality factor of 30, which indicates its efficiency in filtering and power delivery.
The Bourns SRN4026 inductor complies with AEC-Q200 automotive standards and is RoHS compliant.
The termination style of the SRN4026 is solder, making it suitable for surface mount PCB applications.
The maximum self-resonant frequency of the Bourns SRN4026 inductor is 4 MHz, which is relevant for its performance in high-frequency applications.
The SRN4026 features a moulded wirewound construction, which contributes to its durability and precision in performance.
