STMicroelectronics 200 V 1 A Switching Diode Single Rectifier 2-Pin DO-214AC STTH102A
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.03mm |
| Length | 4.6mm |
| Model | STTH102A |
| Width | 2.95mm |
| Mount Type | Surface |
| Series | STTH102 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-214AC (SMA) |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | UL 94 V0 |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 1μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 40A |
| Maximum Forward Voltage Vf | 970mV |
| Peak Reverse Recovery Time trr | 20ns |
Key Features
- This diode features a maximum forward voltage of 970 mV suitable for efficient power handling.
- It offers a high peak non-repetitive forward surge current of 40 A for transient conditions.
- The device operates reliably across a wide temperature range from -65°C to 175°C.
- Its fast peak reverse recovery time of 20 ns enhances switching performance in electronic circuits.
- The package size measures 4.6 mm length, 2.95 mm width, and 2.03 mm height, ensuring compact PCB footprint.
- The diode employs a single switching rectifier configuration with two pins for easy integration.
- Complies with UL 94 V0 flammability standard ensuring safety and durability.
- It is not rated for automotive applications.
Product Description
STMicroelectronics STTH102A Switching Diode is a robust single rectifier designed for surface mount technology applications. It supports 200 V maximum peak reverse repetitive voltage and continuous forward current of 1 A, making it suitable for various electronic power management applications.
The diode's low forward voltage drop of 970 mV contributes to efficient power conversion and reduced energy loss. It comes in a compact DO-214AC (SMA) package with dimensions of 4.6 mm length, 2.95 mm width, and 2.03 mm height, offering a small PCB footprint beneficial for high-density circuits.
With a high peak non-repetitive forward surge current rating of 40 A, the device ensures transient robustness. It exhibits a peak reverse current of only 1 µA which minimizes leakage losses. The operating temperature range from -65°C to 175°C allows deployment in diverse industrial environments.
The diode features a rapid peak reverse recovery time of 20 nanoseconds that enhances switching efficiency and reduces electromagnetic interference in circuits, making it ideal for switching power supplies and converters.
The product meets UL 94 V0 flammability standard, guaranteeing safe operation under typical industrial conditions. While it is not qualified for automotive use, it fits well for industrial, manufacturing, electrical, and electronic system designs requiring reliable switching diodes.
This STMicroelectronics switching diode supports 1 A continuous forward current and 200 V peak reverse voltage ratings. Its fast switching and low forward voltage drop optimize performance in power rectification. The surface mount DO-214AC package facilitates integration into automated PCB assembly lines.
Robustness against surge currents and wide temperature ratings suit demanding industrial applications. The Diode's dimensions support compact electronic system designs. Compliance with UL safety standards enhances product reliability.
Explore the broad range of STMicroelectronics semiconductor components on EnvMart for your electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum peak reverse repetitive voltage of this diode is 200 V.
This model supports a continuous forward current of 1 A.
The package dimensions are 4.6 mm in length, 2.95 mm in width, and 2.03 mm in height.
The maximum forward voltage drop is 970 mV.
It has a peak non-repetitive forward surge current rating of 40 A.
The peak reverse recovery time is 20 ns, enhancing its switching performance.
The operating temperature range is from -65°C to 175°C.
It supports surface mount technology (SMT) for easy integration into circuits.
It complies with the UL 94 V0 flammability standard.
The peak reverse current is 1 μA, which minimizes leakage losses.
No, this diode is not rated for automotive applications.
It employs a single rectifier configuration with two pins for integration.
