Littelfuse PCB Miniature Reed Switch 500 mA 200 V HE721C1200

Free Delivery in India | Lowest Global Shipping Charges

Littelfuse PCB Miniature Reed Switch 500 mA 200 V HE721C1200

Name: Littelfuse PCB Miniature Reed Switch 500 mA 200 V HE721C1200
Brand: LITTELFUSE
SKU: 386951
Price: 681.27 INR
Availability: InStock



Category Reed Switch Brand LITTELFUSE Condition New

Specifications

Country of Origin	China
Brand	Littelfuse
Operating Temperature Range	-40°C to +85°C
Length	20.14mm
Model	HE721C1200
Depth	5.82mm
Width	7.62mm
Mount Type	PCB
Contact Material	Nickel Iron Alloy
Series	HE721
Maximum Switching Current	500mA
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Terminal type	Solder
Contact Resistance	200mΩ
Maximum Switching Power	10W
Standards/Approvals	UR
Maximum Switching Voltage	200V
Maximum Release Time	3ms
Operating Time Including Bounce	1ms

Key Features

Compact SIL dual inline package ensures easy PCB mounting and integration.
Maximum switching current of 500 mA and power of 10 W for moderate load applications.
Operates at voltages up to 200 V with contact resistance of 200 milliohms.
Constructed with nickel iron alloy contacts for durability and performance.
Operating temperature range from -40°C to +85°C suitable for industrial environments.
Solder terminal type enhances secure electrical connections.
Fast response with maximum release time of 3 ms and bounce time of 1 ms.
UL recognized standard compliance provides confirmed safety and quality.

Product Description

Littelfuse HE721C1200 PCB Miniature Reed Switch 500 mA 200 V is a high-quality switching component designed to provide reliable control in electronic and industrial applications. Packaged in a miniature dual inline SIL format, this reed switch is optimized for easy mounting on printed circuit boards.

Equipped with nickel iron alloy contacts, the switch delivers a maximum switching current of 500 mA and a switching power capacity of 10 W, supporting maximum switching voltages of up to 200 V. Its contact resistance is low at 200 milliohms, ensuring efficient conductivity.

The operational range of this reed switch spans from -40°C to +85°C, allowing it to perform reliably across diverse temperature conditions typical in industrial, telecommunications, instrumentation, and security systems.

An important feature is its fast switching capability, with a maximum release time of 3 milliseconds and operating time including bounce of just 1 millisecond, suitable for applications requiring quick and precise signal switching.

Termination is via solder terminals for robust electrical and mechanical connectivity, making it practical for PCB assembly processes. Compliance with UR standards attests to its quality and safety for industrial deployment.

Typical applications extend across security systems, telecom equipment, process control systems, industrial machinery, and instrumentation, where dependable reed switch operation is critical.

Compact SIL dual inline package ensures easy PCB mounting and integration. Maximum switching current of 500 mA and power of 10 W for moderate load applications. Operates at voltages up to 200 V with contact resistance of 200 milliohms.

Constructed with nickel iron alloy contacts for durability and performance. Operating temperature range from -40°C to +85°C suitable for industrial environments. Solder terminal type enhances secure electrical connections.

Fast response with maximum release time of 3 ms and bounce time of 1 ms. UL recognized standard compliance provides confirmed safety and quality. Explore more products in the Reed Switch category at EnvMart for high quality electronic switching solutions.
