Wurth Elektronik 10 mH 3 A Common Mode Choke 0.155 Ω 250V AC WE-LF Series 7446923010
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 20mm |
| Packaging | Tray & Carton |
| Mount Type | Through Hole |
| Series | WE-LF |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Test Frequency | 10kHz |
| Impedance | 65mΩ |
| Inductance | 10mH |
| Number of Lines | 2 |
| Standards/Approvals | RoHS, VDE, ENEC, REACH |
| Maximum DC Current | 3A |
| Pin Count | 4 |
| Maximum DC Resistance | 0.155Ω |
| Inductance Tolerance | ±30 % |
| Choke Voltage | 250V ac |
Key Features
- Inductance rating of 10 mH ensuring effective filtering performance.
- Maximum DC current capacity of 3 A to handle moderate current loads.
- Maximum DC resistance of 0.155 Ω for low power loss.
- Through hole mounting type for secure PCB installation.
- Choke constructed with a toroidal-core having segment winding for superior suppression.
- Operating temperature range from -40°C to 125°C for versatile industrial environments.
- Packaged in tray and carton for protection and easy handling.
Product Description
Wurth Elektronik 7446923010 is a 10 mH, 3 A Common Mode Choke from the WE-LF series, featuring a maximum DC resistance of 0.155 Ω and a choke voltage rating of 250V AC. Designed primarily for use in mains filter circuits, this choke utilizes a dual toroidal-core construction with segment winding that provides effective suppression of common-mode interference across a broad frequency range.
This component employs a high-quality core material, which supports efficient suppression in low to medium frequency ranges, and is well-suited for power electronics, switched-mode power supply units, and EMI filters. The choke has a through-hole mount type with 4 pins, offering secure and reliable installation on printed circuit boards.
The Wurth Elektronik choke can operate reliably within a temperature range from -40°C up to 125°C, ensuring durability in diverse industrial, laboratory, commercial, and manufacturing applications. Its packaging in tray and carton facilitates easy handling and protection during transportation and storage.
Typical applications include mains filters to reduce noise and interference in electronic circuits, power electronics for smoothing currents, and switched-mode power supplies for enhanced electromagnetic compatibility.
Inductance of 10 mH promotes effective noise filtering. Maximum DC current up to 3 A accommodates standard current loads. Low maximum DC resistance of 0.155 Ω reduces power losses. Rated for 250V AC operation in typical mains environments.
Through-hole mounting ensures robust PCB connection. Dual toroidal-core design enables broad suppression frequency range. Wide operating temperature range from -40°C to 125°C for industrial use. Packaging designed for protection and ease of use during installation.
Explore the extensive range of EMI filters and protection components at EnvMart for industrial and electronic applications.
Explore more products in our EMI Filters & Protection category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance rating of this common mode choke is 10 mH, which ensures effective filtering performance.
This model has a maximum DC current capacity of 3 A, allowing it to handle moderate current loads.
The maximum DC resistance of this choke is 0.155 Ω, which helps reduce power loss.
The choke is rated for operation at 250V AC, suitable for typical mains environments.
This unit features a through-hole mounting type, which provides a secure installation on printed circuit boards.
It can operate reliably within a temperature range from -40°C to 125°C, making it suitable for various industrial environments.
This choke has 4 pins for connection, ensuring a reliable installation.
The test frequency for this common mode choke is 10 kHz, which is relevant for its performance evaluation.
This model complies with RoHS, VDE, ENEC, and REACH standards, ensuring it meets various regulatory requirements.
The impedance of this choke is 65 mΩ, which contributes to its effective filtering capabilities.
It is packaged in tray and carton, designed for protection and ease of handling during transportation and storage.
This common mode choke is suitable for mains filters, power electronics, and switched-mode power supplies to reduce noise and interference.
