EMERSON ? ASCO 3 Port Solenoid Valve Stainless Steel Body NC 24V DC 1/4 in E314K121S1V01F1
Specifications
| Country of Origin | Poland |
|---|---|
| Brand | EMERSON ? ASCO |
| Body Material | Stainless Steel |
| Maximum Operating Pressure | 10 bar |
| Outlet Connection Type | Threaded |
| Model | E314K121S1V01F1 |
| Series | E314K |
| Number Of Ports | 3 |
| Maximum Operating Temperature | 90°C |
| Minimum Operating Temperature | -25°C |
| Orifice Diameter | 2.4mm |
| Supply Voltage | 24V dc |
| Inlet Port Size | 1/4 in |
| Default Valve Position | NC |
| Maximum Opening Time | 25ms |
| Flow Factor Kv | 0.17m³/h |
| Outlet Thread Standard | NPT |
| Asco Solenoid Valve, 3 port(s) , NC, 24 V dc, 1/4inBrand | Asco Joucomatic |
Key Features
- Compact three-way solenoid valve with normally closed (NC) default position.
- Constructed with durable stainless steel body suitable for oil, water, and air.
- Operates efficiently at 24V direct current supply voltage.
- Threaded inlet and outlet connections with 1/4 inch size for easy pipeline integration.
- Maximum operating pressure up to 10 bar ensuring robust performance in industrial applications.
- Wide operating temperature range from -25°C to 90°C for versatility.
- Low orifice diameter of 2.4 mm for precise flow control.
- Fast switching times with 25 ms maximum opening and closing times.
Product Description
EMERSON ASCO model E314K121S1V01F1 is a three-port, normally closed solenoid valve equipped with a stainless steel body and threaded connections sized at 1/4 inch. Designed for direct operation, this valve provides rapid switching suitable for controlling air, oil, water, and inert gases in various industrial fluid power applications.
The valve is engineered for compactness and efficiency. It features a low orifice diameter of 2.4 mm enabling precise flow regulation and is optimized for general three-way piloting applications using a minimal number of moving parts. The stainless steel body ensures resistance to corrosion and mechanical wear, facilitating long operational life in demanding environments.
Operating at 24 volts DC, the valve supports a maximum pressure of 10 bar, making it ideal for medium-pressure pipeline systems. It can be installed in any position without compromising performance and includes two mounting holes for secure fixing. Comprehensive installation and maintenance instructions accompany the product.
With an operating temperature range from -25°C to 90°C, this valve adapts well to various environmental conditions. It complies with RoHS directives and other relevant EC standards, although it carries no hazardous area certification. The valve boasts a flow factor Kv of 0.17 m³/h and achieves fast response times with maximum 25 ms for opening and closing actions, aiding in efficient process control.
Suitable for applications in industrial, laboratory, production, hydraulic, pneumatic, and HVAC systems, this valve can be integrated seamlessly into fluid handling and control systems requiring precision and durability.
Compact three-way solenoid valve with normally closed position. Stainless steel body for durability and corrosion resistance. 24 V DC supply voltage compatible with industrial automation. Threaded 1/4 in connections standardized for easy installation.
Maximum operating pressure of 10 bar supports robust system demands. Wide operating temperature range for versatile environmental conditions. Low orifice diameter allows fine flow control and efficiency. Fast switching times enhance process responsiveness.
RoHS compliant and meets relevant EC directives. Manufactured in Poland ensuring high quality standards. For comprehensive solutions in fluid control, browse EnvMart's extensive range of industrial Solenoid Valves and other EMERSON ASCO products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 10 bar, making it suitable for medium-pressure pipeline systems.
This solenoid valve operates at a supply voltage of 24V DC.
It features a stainless steel body, which provides durability and resistance to corrosion.
The orifice diameter is 2.4 mm, allowing for precise flow control.
The valve can operate within a temperature range of -25°C to 90°C.
It has a maximum opening and closing time of 25 ms, enabling rapid switching.
This model features threaded inlet and outlet connections sized at 1/4 inch.
The valve is manufactured in Poland, ensuring adherence to high quality standards.
The flow factor Kv for this valve is 0.17 m³/h.
The default position of this solenoid valve is normally closed (NC).
It is suitable for applications in industrial, laboratory, production, hydraulic, pneumatic, and HVAC systems.
Yes, it complies with RoHS directives and other relevant EC standards, although it does not carry hazardous area certification.
