SL Power / Advanced Energy Industrial Single Output Switching Power Supply 28V DC 20W 90-264V AC GSC20-12G
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | SL Power / Advanced Energy |
| Power | 20W |
| Efficiency | 70% |
| Length | 3.5in |
| Model | GSC20-12G |
| Depth | 0.71in |
| Width | 2.0in |
| Mount Type | Chassis |
| Series | GSC20 |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | 0°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 264V ac |
| Standards/Approvals | UL60950, RoHS (G suffix), IEC60950, EN60950, EMI FCC Class B, CSA-C22.2 No. 60950, CISPR22B, CB Certificate |
| Maximum Output Voltage | 28V dc |
| SMPS Output Current | 3.8A |
| Minimum Input Voltage | 90V ac |
Key Features
- Single output switching power supply with 28V DC maximum output voltage.
- Universal input voltage range from 90 to 264 volts AC.
- Compact chassis mount type with dimensions 3.5 x 2.0 x 0.71 inches.
- Continuous output power of 20 watts with peak power of 24 watts for 60 seconds.
- Operating temperature range from 0°C to 50°C suitable for industrial environments.
- High efficiency up to 70% improving energy usage.
- Fully protected against short circuit and output overload conditions.
- Complies with UL60950, IEC60950, EN60950 safety standards and RoHS (G suffix) compliance.
Product Description
SL Power / Advanced Energy GSC20-12G is an industrial grade switching power supply designed to deliver a regulated 28V DC output at 20W continuous power. It features a single output and operates efficiently within a universal AC input voltage range of 90 to 264 volts, making it suitable for commercial and industrial power supply needs.
This compact supply measures just 3.5 inches in length, 2.0 inches in width, and 0.71 inches in depth, making it ideal for space-conscious installations where chassis mounting is required. The device is rated for operation in ambient temperatures ranging from 0°C to 50°C, providing reliable performance in harsh industrial environments.
The GSC20-12G supports a peak power output of 24W for short durations of up to 60 seconds, offering additional headroom for transient loads. It achieves up to 70% efficiency, contributing to energy savings and reduced thermal output.
Built with built-in short circuit and overload protection, it ensures safe and stable operation under varying loads. Compliance with multiple international safety standards including UL60950, IEC60950, EN60950, and RoHS directives certifies its suitability for global commercial use.
This power supply is manufactured in Mexico under strict quality control, guaranteeing durable and consistent performance in demanding applications. Single output, 28V DC voltage for steady power delivery. Wide input voltage range from 90 to 264V AC to handle different power sources.
Compact and robust chassis mount design for flexible installation. High efficiency of 70% reduces energy consumption. Comprehensive protection against short circuit and overload. International safety approvals for reliable commercial use.
Peak power capacity up to 24W for transient load handling. Operating temperature range suited for industrial conditions. Ideal for electronics, industrial machinery, and commercial power requirements. Made in Mexico ensuring manufacturing quality and reliability.
Explore our wide range of power supplies and switching power supply solutions available on EnvMart for industrial and commercial electronic applications.
Explore more products in our Switching Power Supplies category.
