SL Power / Advanced Energy 3 Output Linear Power Supply 240V, 6A Output Current, 15V Maximum Output Voltage HCBB75W-A+G

SL Power / Advanced Energy HCBB75W-A+G is a high-quality linear power supply designed to provide stable and reliable power for industrial, laboratory, and electronic component applications. It features three outputs that deliver a maximum voltage of 15 volts with a continuous output current capability of 6 amperes, suitable for powering various devices requiring regulated DC power.

This model supports a wide AC input voltage range from 100V up to 240V, enabling global compatibility. Its compact form factor measures 279.4 mm in length, 123.7 mm in width, and 83.31 mm in depth, making it adaptable to constrained installation spaces.

With an operating temperature range from 0°C to 70°C, the power supply maintains performance stability under demanding environmental conditions. It offers excellent electrical characteristics including low ripple and noise of 3 mV peak-to-peak, as well as tight load and line regulation at 1%, ensuring clean and consistent power output.

The efficiency rating of 55% marks its capability to provide dependable power while managing energy consumption effectively. Additionally, the HCBB75W-A+G complies with internationally recognized safety standards such as UL/CSA 60950 and EN/IEC60950-1, giving assurance of electrical safety and reliability.

Designed with robust components like capacitors rated for high ripple current and transformer insulation meeting Class F standards, it promises long-term durability with a mean time between failures (MTBF) exceeding 200,000 hours according to MIL-HDBK-217D standards.

This open frame Linear Power Supply is suitable for challenging industrial applications, including medical electronics requiring low leakage currents, and environments subject to FCC and CISPR22 Class B conducted emission requirements. It is RoHS compliant and built with high-quality materials for extended service life.

Available from EnvMart, this power supply is ideal for users seeking reliable, industrial-grade power solutions with precise regulation and multiple output support. Explore EnvMart for more advanced power supply options and related power management products.

Equipped with three outputs for versatile power distribution. Maximum output voltage of 15 volts ensures stable operation. Supports an output current of up to 6 amperes for demanding loads. Wide input voltage range from 100V to 240V accommodates global use.

Compact dimensions with length 279.4 mm, width 123.7 mm, and depth 83.31 mm. Operating temperature range from 0°C to 70°C for harsh environments. Low ripple and noise at 3 mV peak-to-peak for sensitive electronics. Load and line regulation both at 1% for precise voltage stability.

Energy efficient with 55% efficiency rating. Compliant with UL/CSA 60950 and EN/IEC60950-1 safety standards. Discover the comprehensive range of linear power supplies and other power management products from EnvMart for your industrial and laboratory needs.
