Lovato Electric Modulo Miniature Circuit Breaker, 4-Pole, 25A, Type B, 400V AC, 10 kA Breaking Capacity P1MB4PB25

Lovato Electric P1MB4PB25 Miniature Circuit Breaker is a high-quality electrical protection device designed for industrial and commercial electrical systems. It features a 4-pole configuration which allows simultaneous disconnection of all phases, making it suitable for three-phase power supply applications operating at 400V AC. The device is rated for 25 amperes and has a Type B tripping characteristic, providing reliable protection against overload and short circuit conditions.

The breaker is equipped with a thermal magnetic tripping mechanism that combines thermal tripping for overload conditions with magnetic tripping for short circuit protection, ensuring rapid and precise disconnections when faults are detected. It offers instantaneous break time for enhanced safety and minimizes potential electrical hazards.

The Lovato Modulo series is designed for DIN rail mounting, simplifying installation in standard electrical panels. The screw terminal type ensures secure and stable electrical connections, maintaining reliable performance under various loading conditions.

This miniature circuit breaker offers a rated insulation voltage of 440V and a rated impulse withstand voltage of 4kV, underlining its robustness for demanding electrical environments. The device complies with stringent international standards including CSA, cURus, EAC, IEC/EN/BS 60898-1, IEC/EN/BS 60947-2, and UL 1077, ensuring safety and regulatory compliance.

Compact in size with dimensions of 86.5 mm height, 72 mm width, and 80 mm depth, this MCB is designed to fit easily in electrical switchboards without occupying excessive space. Its IP20 rating offers basic protection against contact with hazardous parts and intrusion of solid objects.

Typical industrial, commercial, and residential applications include electrical panel protection in manufacturing plants, HVAC systems, water treatment facilities, and general electrical distribution setups.

For enhanced system configurations, a selection of add-on blocks is available, compatible with the Lovato Modulo MCB range. Explore more products in the Miniature Circuit Breaker category at EnvMart for comprehensive circuit protection solutions.

Features a 4-pole configuration ensuring multi-line protection. Current rating of 25 amperes suitable for moderate electrical loads. Type B tripping characteristic for instant saturation or overload protection. Compatible with standard DIN rail mounting for ease of installation.

Equipped with screw terminal type for secure electrical connections. Rated insulation voltage of 440V ensuring operational safety. Instantaneous break time with thermal magnetic tripping mechanism. IP20 ingress protection rating for basic safety against solids.

Compact dimensions: Height 86.5 mm, Width 72 mm, Depth 80 mm. Certified to international standards including CSA, cURus, EAC, IEC/EN/BS 60898-1, IEC/EN/BS 60947-2, UL 1077. EnvMart offers a wide range of Lovato Electric products for reliable electrical protection and automation needs.
