Weidmüller W Series 1-Level Brown Disconnect Terminal Block Screw Clamp 250V 10A 1.5mm² 1016000000

Weidmüller 1016000000 W Series Disconnect Terminal Block Brown, model 1016000000, is engineered for secure and efficient electrical connections in industrial and commercial applications. This screw clamp terminal block supports a voltage rating of 250V and a current of 10A, making it ideal for power distribution and control systems.

Manufactured using robust nylon 6.6 material, the block is self-extinguishing to UL94V-0 standards with thermal endurance of 120°C continuous operation and short-term up to 180°C. Designed for 1-level wiring configurations, it accommodates cable cross-section areas up to 1.5 mm² and wire gauges between 26 AWG and 14 AWG. The 6.4 mm pitch ensures neat and compact assembly on ‘Top Hat’ DIN rails compliant with BS5584:1978 and EN 50022 standards.

The terminal employs advanced screw termination with clamping yoke technology, using hardened steel for mechanical strength along with tinned copper current bars for optimal electrical conductivity. Its brown coloration aids in circuit identification and organization.

Operating temperature range from -50°C to 120°C permits use in demanding environments encountered in industries such as manufacturing, automation, and electrical control panels. The design is free from hazardous substances like cadmium and halogen, adhering to environmental standards.

This disconnect terminal block is suitable for a wide variety of uses including industrial machinery panels, control cabinets, and electrical junction boxes where safety, reliability, and ease of installation are critical.

This terminal block supports a voltage rating of 250 volts. It accommodates wire sizes ranging from 26 AWG to 14 AWG with a cable cross-sectional area of 1.5 mm². The block features a 1-level configuration with a pitch of 6.4 mm for compact installation.

The terminal current rating is 10 amperes, suitable for standard electrical loads. Constructed from brown nylon 6.6, it is self-extinguishing to UL94V-0 and rated for continuous operation up to 120°C. The product uses screw terminations with hardened steel clamping yoke technology for mechanical strength.

It is designed for mounting on ‘Top Hat’ DIN rails compliant with BS5584:1978 and EN 50022 standards. Operating temperatures range from -50°C to 120°C, ensuring durability in varied industrial environments. The terminal block is free from cadmium and halogen, enhancing environmental safety.

Choose Weidmüller 1016000000 W Series Disconnect Terminal Block for reliable, safe, and efficient electrical distribution in your industrial and commercial installations. Browse more from Weidmüller products and DIN Rail Terminal Blocks in EnvMart’s extensive electronics catalog.
