Bourns Shielded Wirewound Surface Mount Inductor 5040 Package 4.7 μH ±20% 3.1 A IDC Ferrite Core SRN5040

Free Delivery in India | Lowest Global Shipping Charges

Bourns Shielded Wirewound Surface Mount Inductor 5040 Package 4.7 μH ±20% 3.1 A IDC Ferrite Core SRN5040

Name: Bourns Shielded Wirewound Surface Mount Inductor 5040 Package 4.7 μH ±20% 3.1 A IDC Ferrite Core SRN5040
Brand: BOURNS
SKU: 375905
Price: 0.31 USD
Availability: InStock



Category Power Inductors Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	4mm
Length	5mm
Model	SRN5040
Depth	5mm
Packaging	Reel
Series	SRN5040
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance Range	1.5 to 47 μH
Inductance	4.7μH
Standards/Approvals	RoHS
Package/Case	5040
Maximum DC Current	3.1A
Pin Count	2
Maximum DC Resistance	35mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	27MHz
Minimum Quality Factor	15
Inductor Construction	Wirewound

Key Features

Compact 5040 package size measuring 5mm x 5mm x 4mm.
Ferrite core construction ensures stable inductance performance.
Semi-magnetically shielded design reduces electromagnetic interference.
Maximum operating temperature up to 125°C suitable for harsh environments.
Solder termination style for reliable PCB mounting.
High quality factor minimum of 15 for efficient power delivery.
Low maximum DC resistance at 35mΩ for minimal power loss.
Inductance range available from 1.5 to 47 μH covering various application needs.

Product Description

Bourns SRN5040 shielded wirewound surface mount inductor, model SRN5040, offers 4.7 μH inductance with ±20 % tolerance and supports a maximum DC current of 3.1 A. This inductor features a ferrite core with a semi-magnetically shielded wirewound construction, housed in a compact 5040 package measuring 5mm length, 5mm depth, and 4mm height.

The shielded design effectively reduces electromagnetic interference, making it suitable for sensitive electronic circuits including DC/DC converters, notebooks, digital video cameras, hard disk drives, cellphones, televisions, and LCD displays.

This component operates reliably in temperatures ranging from -40°C to 125°C with a low DC resistance of 35mΩ, ensuring efficiency and minimal power loss. The minimum quality factor of 15 contributes to superior performance in power-sensitive applications.

Designed for surface mount technology with solder terminations, the SRN5040 series inductors are RoHS compliant and moulded for enhanced mechanical strength and environmental protection.

Compact 5040 surface mount package for high-density PCB designs. Semi-magnetically shielded wirewound construction reduces EMI interference. Ferrite core material supports stable inductance under varying conditions. Wide temperature operating range from -40°C to 125°C.

Low DC resistance of 35mΩ minimizes power loss. Suitable for diverse applications such as DC/DC converters, portable electronics, and displays. RoHS compliant and environmentally friendly. Moulded construction ensures durability and reliability.

Solder termination style for easy and secure board assembly.

These inductors are ideal for industrial electronics, telecommunications, consumer devices, and other commercial electronics requiring low noise and efficient power management. Bourns SRN5040 series offers flexible inductance options from 1.5 to 47 μH to meet various circuit demands.
