Wurth Elektronik WE-RFH 1008 Shielded Surface Mount Inductor with Ferrite Core 10 μH ±5% 300 mA 744758410A

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WE-RFH 1008 Shielded Surface Mount Inductor with Ferrite Core 10 μH ±5% 300 mA 744758410A

Name: Wurth Elektronik WE-RFH 1008 Shielded Surface Mount Inductor with Ferrite Core 10 μH ±5% 300 mA 744758410A
Brand: Wurth Elektronik
SKU: 373097
Price: 0.45 USD
Availability: InStock



Category Power Inductors Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Malaysia
Brand	Wurth Elektronik
Height	1.7mm
Length	2.6mm
Model	744758410A
Depth	2.1mm
Packaging	Tape & Reel
Series	WE-RFH
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	10μH
Standards/Approvals	RoHS, REACH, JEDEC JS709B, IEC 61249-2-21
Package/Case	1008
Maximum DC Current	300mA
Maximum DC Resistance	2.8Ω
Inductance Tolerance	±5 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	40MHz
Minimum Quality Factor	15
Inductor Construction	Ferrite Core
Automotive Standard	AEC-Q200

Key Features

Compact 1008 package size suitable for surface mounting.
Ferrite core construction ensures high inductance and low noise.
Rated for maximum DC current of 300 mA with ±5% inductance tolerance.
Operates reliably between -40°C to 85°C ambient temperatures.
Maximum DC resistance of 2.8 Ω supports efficient current flow.
Shielded design reduces electromagnetic interference in sensitive circuits.
Certification compliant with RoHS, REACH, JEDEC JS709B, IEC 61249-2-21 standards.
Designed for RF and telecommunication applications with low acoustic noise.

Product Description

Wurth Elektronik 744758410A WE-RFH 1008 shielded surface mount inductor incorporates a ferrite core with a nominal inductance of 10 μH and an inductance tolerance of ±5%. It supports a maximum DC current of 300 mA and operates reliably within the temperature range of -40°C to 85°C. The component features a compact 1008 package size with dimensions 2.6 mm length, 2.1 mm depth, and 1.7 mm height.

These wire wound inductors are designed to minimize acoustic and leakage flux noise, making them ideal for RF circuits and telecommunication equipment requiring high signal integrity. The inductor’s maximum DC resistance is specified at 2.8 Ω, ensuring efficient performance under rated current conditions.

The WE-RFH series inductors are shielded to reduce electromagnetic interference, enhancing performance stability. They meet automotive standard AEC-Q200 and comply with RoHS, REACH, JEDEC JS709B, and IEC 61249-2-21 standards, guaranteeing quality and regulatory compliance.

Compact 1008 package for surface mount technology. Ferrite core construction for high inductance. Maximum DC current of 300 mA with low resistance. Operating temperature range from -40°C to 85°C. Shielded design minimizes EMI and acoustic noise.

RoHS and REACH compliant with industry standards. Tape and reel packaging supports automated manufacturing. Suitable for RF and telecommunication applications. Quality factor minimum of 15 ensuring efficient inductance.

This product is factory new and sourced from Malaysia. It is ideally used in industrial electronics, telecommunications, RF signal processing, and other surface mount applications requiring reliable inductive components.
