TE Connectivity SL-156 Female Connector Housing 3.96 mm Pitch 9 Way 1 Row Straight 770849-9

TE Connectivity 770849-9 Female Connector Housing is a high-quality electrical connector component featuring a 3.96 mm pitch, 9 ways, and 1 row in a straight orientation. Manufactured using UL94V-0 rated white nylon, this housing is flame retardant and designed for durable wire-to-board connections in electronic and power connector applications.

This housing mates with 1.14 mm square or round post headers or staked posts on 0.156 inch centres, commonly used in industrial, manufacturing, and electronics assembly environments. The end-to-end stackable design facilitates compact and efficient wiring organization.

The connector supports wire sizes from 18 to 24 AWG, accommodating a range of cable thicknesses. For improved reliability, the housing includes both locking ramp mating retention and polarizing tabs to prevent incorrect connections and ensure secure engagement during operation.

The 770849-9 model is part of the SL-156 series from TE Connectivity, known for compatibility with Tyco AMP CST 100 range components. Its cable mount feature and precise dimensions (length 35.61 mm, width 16.76 mm) make it versatile for various industrial and electronic applications including automation, control systems, and power distribution.

Made from UL94V-0 rated white nylon ensuring flame retardance. Compatible with 1.14 mm square or round post headers on 0.156 inch centres. Stackable end to end for compact design flexibility. Accepts wire size range from 18 to 24 AWG.

Features locking ramp mating retention and polarizing tabs for secure connection. Designed for a cable mount with straight orientation and 9 contacts. Length of 35.61 mm and width of 16.76 mm.

This TE Connectivity SL-156 female connector housing is ideal for use in electronics manufacturing, aerospace, automotive, industrial automation, HVAC controls, telecommunications, and power supply assemblies, providing reliable and secure electrical connections.
