TE Connectivity Thermal Circuit Breaker W58-XB1A4A-6 6A Current Rating 1-Pole Direct Mount 250V AC 50V DC
Specifications
| Country of Origin | China |
|---|---|
| Range | 0.5 to 30 A |
| Brand | TE Connectivity |
| Model | W58-XB1A4A-6 |
| Width | 16.76mm |
| Mount Type | Direct |
| Current Rating | 6A |
| Series | W58 |
| Terminal type | Screw |
| Breaking Capacity | 1000A |
| Number of Poles | 1 |
| Standards/Approvals | CE, RoHS |
| Rated AC Voltage | 250V ac |
| Rated DC Voltage | 50V dc |
| Tripping Characteristics | 101%-145%, Must trip at 145% at 25°C |
| Tripping Mechanism | Thermal |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 18.8 mm |
| Break Time | Medium |
Key Features
- This thermal circuit breaker is rated for 250V AC and 50V DC operation.
- Features a toggle switch reset actuator for easy manual reset.
- Tripping characteristics are 101% to 145%, ensuring trip at 145% at 25°C.
- Mounting is direct with an 18.8 mm mount hole size and uses screw terminals.
- The breaking capacity is 1000A with medium break time performance.
- Meets CE and RoHS standards ensuring compliance and safety.
- Ideal for electrical automation, control panels, and circuit protection applications.
Product Description
TE Connectivity W58-XB1A4A-6 Thermal Circuit Breaker is designed for reliable circuit protection in various electrical and automation applications. This 6A rated, 1-pole device is optimized for use in AC up to 250V and DC up to 50V circuits, making it versatile for industrial and commercial installations.
The breaker incorporates a thermal tripping mechanism with 101%-145% tripping range, guaranteeing a trip at 145% of rated current at standard ambient temperature of 25°C. The toggle switch reset actuator enables quick manual reset after a trip event, facilitating maintenance and reducing downtime.
Direct mount installation with an 18.8 mm hole size simplifies panel integration while the compact width of 16.76 mm saves space. Screw terminals ensure secure wiring connections for reliable electrical contact under operational stress.
This breaker supports a breaking capacity of 1000A with medium break time characteristics, suitable for protecting sensitive equipment against overloads and short circuits. Compliance with CE and RoHS standards endorses quality and environmental safety.
Rated current: 6A. Single pole design for straightforward circuit protection. Toggle switch for convenient reset. Wide operational range from 0.5 to 30 A (series W58). Compact size and robust construction enhances durability.
Applications include industrial automation, electrical panels, and HVAC control circuits. Product of China with assured quality standards. Explore more TE Connectivity circuit protection solutions in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This thermal circuit breaker has a current rating of 6A.
It is rated for a maximum AC voltage of 250V and a DC voltage of 50V.
The tripping characteristics range from 101% to 145%, with a guaranteed trip at 145% at 25°C.
It features a toggle switch reset actuator for easy manual reset after a trip event.
The breaking capacity is rated at 1000A.
This model is designed for direct mounting with a mount hole size of 18.8 mm.
The width of this thermal circuit breaker is 16.76 mm.
It meets CE and RoHS standards for compliance and safety.
It uses screw terminals for secure wiring connections.
It is suitable for applications in industrial automation, electrical panels, and HVAC control circuits.
The tripping mechanism is thermal, designed to respond to overload conditions.
This model supports a current range from 0.5 to 30 A.
