Eaton Non-Resettable Fuse, Radial Lead 6.3A, 300V AC Time Delay Plastic Body SR-5H-6-3A-BK

Free Delivery in India | Lowest Global Shipping Charges

Eaton Non-Resettable Fuse, Radial Lead 6.3A, 300V AC Time Delay Plastic Body SR-5H-6-3A-BK

Name: Eaton Non-Resettable Fuse, Radial Lead 6.3A, 300V AC Time Delay Plastic Body SR-5H-6-3A-BK
Brand: Eaton
SKU: 367242
Price: 1.26 USD
Availability: InStock



Category Non-Resettable Fuse Brand Eaton Condition New

Specifications

Country of Origin	China
Voltage	300V ac
Diameter	8.5mm
Brand	Eaton
Body Material	Plastic
Height	9.2mm
Length	8.7mm
Model	SR-5H-6-3A-BK
Width	8.5mm
Current Rating	6.3A
Series	SR-5H
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Lead Length	4.3mm
Breaking Capacity	100A
Lead Diameter	1mm
Fuse Characteristics	Time Delay
Lead Orientation	Radial

Key Features

The fuse features a plastic body made of thermoplastic polyamide material.
It has radial lead orientation with 4.3mm lead length and 1mm lead diameter.
The fuse supports a breaking capacity of 100A suitable for primary and secondary overcurrent protection.
Operating temperature range is from -40°C minimum to 85°C maximum, compliant with IEC and UL standards.
The fuse characteristics include time delay, allowing high inrush current tolerance.
It is compatible with leaded and lead-free reflow and wave solder processes.

Product Description

Eaton SR-5H-6-3A-BK Non-Resettable Fuse is a radial lead time-delay fuse rated for 6.3A current and 300V AC voltage. This fuse is equipped with a durable plastic thermoplastic polyamide body, ensuring reliable performance within industrial, electrical, and automation applications.

The fuse features a body length of 8.7mm, diameter and width of 8.5mm, and height of 9.2mm. Radial leads measure 4.3mm in length and 1mm in diameter, facilitating easy PCB mounting and integration.

Designed to handle a maximum breaking capacity of 100A, this fuse provides effective protection against overcurrents in primary and secondary electrical circuits. Its time delay characteristic supports high inrush currents, making it suitable for demanding industrial and electronic environments.

Operating temperature ranges from -40°C to 85°C, ensuring performance stability across varied ambient conditions. The fuse complies with stringent international standards including IEC 60127-3, UL 94V0, IEC 60068-2-20, and RoHS directives, confirming its quality and environmental compliance.

Manufactured in China, the SR-5H series by Eaton (formerly Cooper Bussmann) is widely recognized for robustness and compatibility with leaded and lead-free reflow and wave solder processes, making it an ideal protection component for PCB applications.

The fuse body is made from thermoplastic polyamide ensuring durability. Radial lead orientation with precise lead length and diameter for secure installation. Time delay design allows high surge current tolerance while protecting circuits.

Breaking capacity of 100A supports reliable overcurrent protection. Meets multiple high-standard certifications for safety and quality assurance. Operates effectively within a wide temperature range for versatile applications.

Suitable for use in industrial, electrical, automation, and PCB protection applications.
