Weidmüller BL Series Pluggable Terminal Block, 6-Contact, 3.5 mm Pitch, 1 Row, Male Connector, Screw Connection 1639050000

Weidmüller 1639050000 Pluggable Terminal Block is a high-quality electrical connector featuring 6 contact positions arranged in a single row with a 3.5 mm pitch, designed for industrial and electronic applications requiring secure and efficient wiring solutions. Its robust polybutylene terephthalate housing provides excellent insulation and mechanical strength, suitable for demanding environments.

This terminal block supports a rated current of 12 amperes and an operating voltage of 320 volts. The screw connection method, combined with a male connector gender, ensures secure connectivity and easy wire termination. It accommodates wire sizes from a minimum of 0.08 mm² (28 AWG) up to a maximum of 2.5 mm² (14 AWG), making it versatile for various circuit requirements.

The compact form factor measures 22.45 mm in width and 14.6 mm in depth, featuring an orange color for clear identification during installation. The connection system includes a hardened, zinc-chromed plated clamping yoke steel that enhances connection reliability and longevity by protecting against corrosion.

Designed with safety in mind, this terminal block conforms to UL94 V-0 flammability class standards, providing flame retardancy for electrical components. The product belongs to the Weidmüller BL series and fits seamlessly with the Omnimate connector range, optimized for cost-effective and space-saving PCB mounting in either vertical or horizontal orientations.

Common industrial use cases include applications in electronics manufacturing, industrial automation, control panels, and other electrical assembly tasks requiring reliable wire-to-board connections. Compatible flanged headers are available separately under RS stock numbers (180°) 762-6343 and (90°) 762-6303 to complement this terminal block system.

Constructed with polybutylene terephthalate housing for durability and insulation. Supports a rated current of 12 A and voltage up to 320 V. Offers screw type wire connection with male connector gender for secure wiring.

Wire size compatibility ranges from 0.08 mm² (28 AWG) up to 2.5 mm² (14 AWG). Compact design with dimensions: width 22.45 mm and depth 14.6 mm. Orange colored housing allows for easy identification in assemblies. Equipped with a hardened, zinc-chromed plated clamping yoke steel for reliable connections.

Complies with UL94 V-0 flammability class ensuring safety in electrical applications. Ideal for PCB applications with vertical or horizontal headers, compatible with Weidmüller Omnimate range. Explore the Weidmüller category on EnvMart for a broad range of industrial and electronic connectors and terminal blocks designed to meet your project's exact requirements.
