RS PRO Push Button Switch Momentary Panel Mount SPDT 6.35 mm Cutout White LED 28V dc 120V ac 734-6785

RS PRO 734-6785 Push Button Switch is a high-quality momentary panel mounting switch designed for efficient electrical circuit control in commercial, industrial, and medical applications. Featuring a white cap actuator and a panel cutout diameter of 6.35 mm, this Single Pole Double Throw (SPDT) switch supports both 28 V dc and 120 V ac operating voltages.

The switch is fitted with silver-plated copper alloy contacts that provide excellent electrical conductivity and minimize voltage drops, ensuring reliable signal transmission during operation. Its solder terminal type allows straightforward panel mounting on hard surfaces, facilitating quick and firm installation.

Designed for robust performance, this momentary push button has a mechanical life expectancy of up to 50,000 make-and-break cycles, making it well-suited for repeated operations such as reset functionality in industrial plant equipment, production lines, and arcade game consoles.

With a contact current rating of 3A at 120 V AC and a maximum operating temperature of 85°C, this switch meets industrial standards including RoHS compliance and lead-free construction for environmentally responsible use.

The switch operates momentarily for precise circuit control. SPDT contact configuration offers flexible electrical switching. Panel cutout size is 6.35 mm diameter for standard installation. Silver-plated copper alloy contacts ensure excellent conductivity.

Contact current rating of 3A at 120 V AC, and DC voltage rating of 28 V. Durable mechanical life spans up to 50,000 cycles. Solder terminal type for secure panel mounting. RoHS and lead-free compliant for safety and environmental standards.

Maximum operating temperature is 85°C suitable for industrial environments. Applications include telecommunication, instrumentation, medical, industrial equipment, and arcade games.

This Push Button Switch represents a reliable solution for multiple industrial and commercial applications, providing efficient control and compliance with environmental safety standards. Explore the RS PRO range for more electrical components and switches designed to enhance production efficiency and system control.
