TE Connectivity MULTILOCK 070 II Female Connector Housing 5.5 mm Pitch 12 Way 2 Row Straight 176116-6

TE Connectivity 176116-6 MULTILOCK 070 II Female Connector Housing is a robust and compact cable-mounted female connector housing designed with a 5.5 mm pitch and 12-way, 2-row straight configuration. It is engineered to provide secure and reliable electrical connections in automotive wire to wire and wire to board applications.

Constructed from durable Polybutylene Terephthalate, the housing is designed to protect contacts against damage caused by KOJIRI Action, which occurs during the mating and unmating stages, enhancing the longevity and reliability of the connection.

The MULTILOCK 070 II series female connector features a sophisticated integral double locking mechanism with a two-piece double lock plate, ensuring secure contact retention and preventing partial insertion. This makes it suitable for critical automotive applications where connection integrity is paramount.

With a compact and high-density design, the connector supports 12 female contacts arranged in 2 rows with a 5.5 mm pitch, accommodating a mixture of .040 terminals for signal circuits and .070 terminals for power circuits. Its straight cable mounting orientation simplifies installation in tight automotive spaces.

The MULTILOCK 070 series is widely used in automotive powertrain systems, safety and security systems, driver information systems, body and chassis electronics, and convenience feature applications, making it a versatile solution for modern automotive electrical architecture.

The housing measures approximately 31.8 mm in length and 31.9 mm in width, enabling compact integration within assemblies. The Connector Housing must be paired with female crimp contacts (ordered separately) to complete the connection interface in automotive wiring harnesses.

Compact design suitable for automotive wire to wire and wire to board connections. Constructed with Polybutylene Terephthalate housing material for enhanced durability. Features a locking mechanism with integral double lock plates for secure contact retention.

High density 5.5 mm pitch with a total of 12 female contacts arranged in 2 rows. Connector protects contacts against KOJIRI Action for damage prevention during mating/unmating. Compatible with a mixture of .040 terminals for signal circuits and .070 terminals for power circuits.

Offers straight cable mounting facilitating ease of use in various applications. Designed for automotive systems including powertrain, safety, security, and driver information. Housing dimensions approximately 31.8 mm length and 31.9 mm width for compact installation.

Series: MULTILOCK 070 II, suitable for demanding automotive electrical environments.
