KNITTER-SWITCH MP Series Miniature Push Button Switch, Momentary, Panel Mount, 5.6 mm Cutout, DPDT, White LED, IP67 MPE206R
Specifications
| Country of Origin | China |
|---|---|
| Brand | KNITTER-SWITCH |
| Model | MPE206R |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | MP |
| Maximum Operating Temperature | 120°C |
| Contact Configuration | DPDT |
| Switch Configuration | On-Off |
| Panel Cutout Size | 5.6 mm |
| Terminal type | Solder |
| Standards/Approvals | CSA, UL |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 702-3460Brand: KNITTER-SWITCHManufacturers Part No.: MPE206R |
| LED Colour | White |
| Switch Operation | Momentary |
| Actuator Colour | Silver |
| Actuator Style | Plunger |
| Switch Contact Current | 3A |
| Contact AC Voltage | 250V ac |
Key Features
- The switch has a 5.6 mm panel cutout size and a silver-colored actuator plunger.
- It features white LED illumination and is rated IP67 waterproof for reliable use in harsh environments.
- Designed to operate at 250 V AC with a contact current rating of 3A and CSA, UL approvals.
- Constructed for durability with a maximum operating temperature of 120°C and epoxy-sealed flux proof design.
- The switch has silver-plated contacts with contact resistance less than 10mΩ and insulation resistance above 1000MΩ.
- It uses solder terminals with an M6 bush and is designed for waterproof applications (MPE series).
- Suitable for industrial, automation, electrical panel control, and other applications requiring momentary switch functionality.
Product Description
KNITTER-SWITCH MPE206R is a MP Series miniature push button switch designed for panel mounting with a 5.6 mm cutout. It is a momentary switch with a DPDT (Double Pole Double Throw) contact configuration, supporting white LED illumination for status indication. This switch is rated IP67, making it waterproof and suitable for harsh, industrial environments.
Operating at 250 V AC with a contact current of 3A, it meets CSA and UL standards, ensuring reliable and safe usage. The actuator color is silver with a plunger style, providing tactile feedback. The switch can handle temperatures up to 120°C, featuring a robust epoxy-sealed flux proof construction that ensures durability and longevity.
The contacts are silver-plated with low contact resistance (less than 10mΩ) and high insulation resistance (>1000MΩ). The MPE series switches use solder terminals and an M6 bush for secure mounting.
These miniature push button switches are ideal for industrial automation, panel controls in electrical systems, and environments where waterproof and reliable switching is critical. Accessories such as a brass chromium-plated bezel and a 15 mm diameter black actuator button are available separately for enhanced functionality.
The switch provides momentary or alternate switching functions with a maximum switch rating of 6A at 125Vac and 3A at 250Vac. The waterproof IP67 rating ensures the switch performs well in wet or dusty environments. Designed to operate within a temperature range from -45 to +140°C for varied industrial applications.
The epoxy-sealed construction provides flux-proof reliability in harsh conditions. Explore KNITTER-SWITCH product lines and other Push Button Switches on EnvMart for quality industrial electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MPE206R switch features a DPDT (Double Pole Double Throw) contact configuration.
This model requires a panel cutout size of 5.6 mm.
The maximum operating temperature for the MPE206R is 120°C.
The push button switch has an IP67 rating, making it waterproof and suitable for harsh environments.
The contact current rating for this switch is 3A.
It uses solder terminals for secure connections.
The MPE206R meets CSA and UL standards, ensuring reliable and safe usage.
The actuator style of this switch is a plunger.
The switch features white LED illumination for status indication.
This switch is suitable for industrial automation, electrical panel control, and other applications requiring momentary switch functionality.
The contact AC voltage rating for the MPE206R is 250V AC.
The insulation resistance of this switch is above 1000MΩ.
