Phoenix Contact 9-Contact Female D-Sub Interface Module DIN Rail Mount 2.5A 25/60V AC 2293666

Phoenix Contact 2293666 is a 9-contact female interface module designed for DIN rail mounting applications, featuring a D-Sub connector type and capable of handling currents up to 2.5A at voltages of 25 and 60V AC. It is engineered for reliable industrial use, offering a compact size and robust connection method.

The module’s tension spring connection terminals provide secure and maintenance-free wiring for wire sizes 14 and 24 AWG (0.2 to 2.5mm² cable CSA). Its orientation is straight, making it suitable for straightforward cabling layouts on DIN rails NS 35 / 7.5.

This interface module is capable of withstanding test proof voltages up to 800V AC, ensuring electrical safety in demanding environments. It operates efficiently within a temperature range of -20°C minimum to 50°C maximum, supporting broad industrial automation applications.

The physical dimensions are length 54mm, width 50mm, and depth 45mm, giving it a compact form factor for tight spaces. Identification labels on side components assist in quick identification during installation or service works. The metallic connector shell is directly linked to a connection terminal to provide earth contact, enhancing grounding reliability.

Features a 9-contact female D-Sub connector designed for interface modules. Supports current rating of 2.5A and voltage levels of 25, 60V AC. Compact size with dimensions 54 x 50 x 45 mm for space-saving. DIN rail mounting type provides easy integration on NS 35 / 7.5 systems.

Operating temperature range of -20°C to 50°C suitable for industrial environments. Tension spring connection terminals allow for secure wiring of 14 and 24 AWG wires. Test proof voltage rating of 800V AC for electrical safety compliance.

Identification labels for quick and clear component recognition. Metallic shell linked to connection terminal for effective earth contact.

This module is suitable for industrial automation, electronic component assemblies, electrical enclosures, and signal interfacing tasks requiring robust, compact, and reliable DIN rail mount connectors. It is manufactured in Germany, ensuring high-quality standards and durability.
