Schneider Electric LC1K Contactor 24V AC Coil, 3-Pole, 9A, 4 kW Power, 3 NO, 690V AC LC1K0901B7

Schneider Electric LC1K0901B7 is a reliable and compact 3-pole contactor with a 24V AC coil designed specifically for motor control and resistive load applications. This model supports a contact current of 9A and a contact voltage rating of 690V AC, making it suitable for industrial and automation use where efficient switching in compact spaces is required.

The contactor features three normally open (3 NO) contacts alongside a single normally closed (1 NC) auxiliary contact, providing advanced signaling and control for diverse electrical automation systems. It is engineered to handle a power rating of 4 kW for medium-load motor drives operating at 380 to 415V.

Its screw clamp terminals enable secure wiring connections for conductors ranging from 0.34 to 4 mm² solid and flexible wires, ensuring installation flexibility and durability. The unit is designed to be mounted on plates or DIN rails within control panels or distribution enclosures, optimized for compact machine control and space-limited applications.

The LC1K0901B7 contactor's high impulse withstand capability of 8 kV and rated making capacity of 110A AC help protect the unit and connected loads against electrical transients and reduce contact wear during high inrush currents common in motor start-ups. It is certified to meet multiple international standards including CCC, EAC, CSA, UL, RoHS, and IEC approaches, reflecting quality and safety.

This contactor operates reliably within a temperature range of -25°C to +50°C and can be used at altitudes up to 2,000 meters, making it suited for a variety of industrial environments. Originating from France, this product embodies Schneider Electric's commitment to quality and durability in electrical control components.

Operates efficiently with 24V AC coil voltage for precise motor and load control. Compact 3-pole design with 9A rating suitable for factory automation. Power rating of 4 kW at 380-415V supports medium-load motor applications.

Includes one normally closed auxiliary contact for signaling functions. Screw clamp terminals ensure secure and flexible conductor connections. Designed for both plate and DIN-rail mounting in control panels. High impulse withstand and rated making capacity enhance durability.

Wide operational temperature range suits varied industrial climates. Conforms to international standards for safety and performance. Explore the full range of Schneider Electric automation and control gear products on EnvMart to optimize your industrial electrical systems.
