Dialight Yellow Right Angle PCB LED Indicator 5 mm (T-1 3/4), 1 LED, 7.5 V, Single Colour 550-0807F
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Dialight |
| Length | 13.85mm |
| Model | 550-0807F |
| Mount Type | Through Hole |
| Series | 550 |
| Number Of Leds | 1 |
| Maximum forward current | 30mA |
| Viewing angle | 60 ° |
| Sub Type | Single Colour |
| Power Dissipation | 80mW |
| Lens Colour | Yellow |
| Luminous Intensity | 8mcd |
| Standards/Approvals | UL 94 V-0, RoHS, MIL-STD-202F |
| LED Colour | Yellow |
| Number of Pins | 2 |
| Lens Finish | Diffused |
| Minimum Supply Voltage | 7.5V |
| LED Material | GaAsP, GaP |
| Multicolour/Single Colour | Single Colour |
| LED Orientation | Right Angle |
| LED Size | 5 mm (T-1 3/4) |
| Dialight LED 550-0807Brand | Dialight |
Key Features
- This PCB LED indicator uses a single yellow LED with a right angle orientation.
- It has a through-hole mount type with 2 pins for easy PCB installation.
- The LED size is 5 mm (T-1 3/4) with a diffused yellow lens finish.
- Maximum forward current is 30 mA, with luminous intensity of 8 mcd.
- The viewing angle is 60 degrees for clear visibility.
- Power dissipation is rated at 80 mW.
- Constructed with GaAsP and GaP LED materials for reliable performance.
- Housing is black plastic with a sloped back to assist PCB cleaning and high contrast display.
Product Description
Dialight 550-0807F is a yellow right angle PCB LED indicator measuring 5 mm (T-1 3/4) designed for electronic components requiring single colour visual signalling. It features a single LED with right angle orientation capable of operating at a minimum supply voltage of 7.5 V, making it ideal for circuit board applications requiring clear indication.
This PCB LED indicator utilizes through-hole mounting with two pins, ensuring secure and reliable installation on printed circuit boards. The LED is constructed from GaAsP and GaP materials, known for stable luminous output and longevity.
The lens is diffused in yellow colour, offering optimal light diffusion with a 60-degree viewing angle for enhanced visibility in various industrial and electronic environments. It dissipates a maximum power of 80 mW and supports a forward current up to 30 mA.
The indicator is housed in a black plastic casing with a sloped back and standoffs to facilitate PCB cleaning and maintain high visual contrast. This quality design complies with stringent UL 94 V-0 flammability standards, RoHS compliance, and MIL-STD-202F reliability testing, making it suitable for diverse industrial, commercial, and manufacturing PCB applications.
This product is manufactured in Mexico, assuring manufacturing quality and standards. This PCB LED indicator uses a single yellow LED with a right angle orientation. It has a through-hole mount type with 2 pins for easy PCB installation.
The LED size is 5 mm (T-1 3/4) with a diffused yellow lens finish. Maximum forward current is 30 mA, with luminous intensity of 8 mcd. The viewing angle is 60 degrees for clear visibility. Power dissipation is rated at 80 mW.
Constructed with GaAsP and GaP LED materials for reliable performance. Housing is black plastic with a sloped back to assist PCB cleaning and high contrast display. Complies with UL 94 V-0, RoHS, and MIL-STD-202F standards.
Made in Mexico, providing quality assurance. Explore the Electronics Components and PCB LED Indicator categories to find more reliable indicators and related accessories for industrial and manufacturing requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward current for this model is 30 mA.
This unit requires a minimum supply voltage of 7.5 V for operation.
The luminous intensity of the yellow LED is 8 mcd.
The viewing angle of this LED indicator is 60 degrees, providing clear visibility.
It features a through-hole mount type with 2 pins for easy installation on PCBs.
The LED is constructed from GaAsP and GaP materials, known for stable performance.
The length of this model is 13.85 mm, with a size of 5 mm (T-1 3/4).
It complies with UL 94 V-0, RoHS, and MIL-STD-202F standards.
The power dissipation for this model is rated at 80 mW.
The lens finish is diffused yellow, which enhances light diffusion.
This PCB LED indicator is manufactured in Mexico.
This model belongs to the 550 series of LED indicators.
