Solartron Metrology Linear Variable Differential Transformer LVDT Sensor 911315-RS
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Solartron Metrology |
| Model | 911315-RS |
| IP Rating | IP43 |
| Maximum Operating Temperature | 60°C |
| 1 channel oscillator/demodulator LVDTBrand | Solartron Metrology |
Key Features
- The sensor features IP43 rating for protection against limited dust ingress and water spray.
- Constructed with a robust die-cast aluminium housing and uses a 5-pin DIN connector.
- Operates at 120Va.c. or 240Va.c. using an external power supply unit for safety and reduced size.
- Provides both -10 to 10V and -20 to 20mA output signals with independent gain and offset adjustments.
- Includes selectable excitation frequency and load resistances for versatile use.
- Supports half-bridge transducers with simple wiring modifications.
- Offers forward and reverse connection selection to simplify wiring without swapping connectors.
- Designed for industrial applications requiring infinite resolution and high linearity with no wear.
Product Description
Solartron Metrology 911315-RS Linear Variable Differential Transformer (LVDT) sensor is a precision motion control device designed for position measurement in industrial, laboratory, and manufacturing applications. The device features a robust die-cast aluminium enclosure with a 5-pin DIN connector, providing reliable operation in demanding environments.
This LVDT operates on an external 120Va.c. or 240Va.c. power supply unit which isolates mains voltage, ensuring safety and allowing a smaller form factor. The output options include both voltage (-10 to 10V) and current (-20 to 20mA) signals with fully independent gain and offset adjustment features.
The sensor accommodates wide range span and zero control, with selectable transducer excitation frequencies and load resistances to match various sensor configurations. Forward and reverse connection selection enables simple wiring without the need to swap wires in the connector. It can support half-bridge transducers with a simple plug wiring change.
Distinct advantages of this LVDT include infinite resolution, high accuracy, and linearity with no friction or wear in the measurement system. The device uses a movable nickel iron core with three coils and requires a sine wave excitation signal. The output signal’s amplitude and phase are directly proportional to core position concerning pickup coils, decoded by a phase sensitive detector.
Typical use cases include industrial automation, manufacturing process control, laboratory instrumentation, HVAC systems, and automation systems requiring precise position sensing.
IP rating IP43 for moderate protection against dust and sprays. Maximum operating temperature of 60°C ensures suitability for typical industrial environments. Manufactured in the United Kingdom under stringent quality controls.
The package is supplied with instructions and a 5-pin DIN plug for ease of installation. Explore more sensors and motion control devices in the Electronics & Electricals category at EnvMart for your industrial automation needs.
Explore more products in our Motion Control Sensors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides output signals of -10 to 10V and -20 to 20mA, allowing for versatile measurement capabilities.
It operates at either 120Va.c. or 240Va.c. using an external power supply unit, which isolates mains voltage for safety.
The sensor is equipped with a 5-pin DIN connector for reliable connections in various applications.
It has an IP43 rating, providing protection against limited dust ingress and water spray.
The maximum operating temperature is 60°C, making it suitable for typical industrial environments.
Yes, it supports half-bridge transducers with simple wiring modifications.
It is designed for industrial, laboratory, and manufacturing applications requiring precise position measurement.
Yes, it provides independent gain and offset adjustments for both output signal types.
It comes with installation instructions and a 5-pin DIN plug, facilitating straightforward setup.
The sensor features a robust die-cast aluminium housing, ensuring reliability in demanding environments.
It operates using a movable nickel iron core with three coils, requiring a sine wave excitation signal for measurement.
It is manufactured in the United Kingdom under stringent quality controls.
