Siemens SENTRON 5SY6 Miniature Circuit Breaker, 3-Pole, 25A, Type B, 400V AC, 72V DC, 6 kA Breaking Capacity 5SY6325-6
Specifications
| Country of Origin | Germany |
|---|---|
| Range | SENTRON |
| Brand | Siemens |
| Height | 90mm |
| Model | 5SY6325-6 |
| Depth | 76mm |
| IP Rating | IP20 |
| Enclosure | IP20 equipment |
| Width | 53mm |
| Mount Type | DIN Rail |
| Current Rating | 25A |
| Series | 5SY6 |
| Terminal type | Screw |
| Breaking Capacity | 6kA |
| Number of Poles | 3 |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 72V dc |
| Tripping Characteristics | Type B |
| Better World Claim | Extended Product Life |
| Curve C | Tripping: 5 to 10 times the rated current |
| Curve D | Tripping: 10 to 14 times the rated current |
| Siemens MCB3P, 25A Curve BBrand | Siemens |
Key Features
- This MCB supports a rated AC voltage of 400V and a rated DC voltage of 72V.
- It features a breaking capacity of 6 kA ensuring safe disconnection under fault conditions.
- The device uses Type B tripping characteristics suitable for protection of generators and long cables.
- Mounting is DIN rail compatible with screw terminal connections for secure wiring.
- The enclosure has an IP20 rating for equipment protection.
- Standards compliance includes IEC 60898, EN 60898, CSA C22.2 No.235, and UL 1077.
Product Description
Siemens 5SY6325-6 SENTRON Miniature Circuit Breaker is a high-quality 3-pole device designed for industrial, residential, and functional building applications. It delivers dependable protection against overloads and short circuits with a current rating of 25A. The Type B tripping characteristic is optimized for sensitive circuits including generators, persons, and long cable runs, tripping at 3 to 5 times the rated current.
Rated for 400V AC and 72V DC voltages, this MCB supports mixed load environments. It offers a breaking capacity of 6 kA, ensuring safe interruption of fault currents and enhanced safety for electrical installations. The device mounts easily on DIN rails and uses screw terminals, making installation fast and secure while supporting quick removal for maintenance.
The compact dimensions of 90mm height, 53mm width, and 76mm depth conserve panel space. The IP20 enclosure rating safeguards the internal mechanism against accidental contact and solid foreign objects. This product complies with internationally recognized standards including IEC 60898, EN 60898, CSA C22.2 No.235, and UL 1077 to guarantee quality and reliability.
Typical industrial, HVAC, manufacturing, and commercial electrical protection applications benefit from its robust design and extended product life. Supplementary components such as control switches and signal contacts can be combined with this MCB for customized protection solutions.
This MCB supports a rated AC voltage of 400V and a rated DC voltage of 72V. It features a breaking capacity of 6 kA ensuring safe disconnection under fault conditions. The device uses Type B tripping characteristics suitable for protection of generators and long cables.
Mounting is DIN rail compatible with screw terminal connections for secure wiring. The enclosure has an IP20 rating for equipment protection. Compact dimensions of 90mm height, 53mm width, and 76mm depth allow easy installation.
Complies with IEC 60898, EN 60898, CSA C22.2 No.235, UL 1077 safety standards. Explore more Siemens electrical protection devices and circuit breakers at EnvMart for reliable industrial and commercial use.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 25A, making it suitable for various electrical protection applications.
It features a breaking capacity of 6 kA, ensuring safe interruption of fault currents.
This MCB supports a rated AC voltage of 400V and a rated DC voltage of 72V.
It uses Type B tripping characteristics, which are optimized for protection of sensitive circuits such as generators and long cable runs.
The dimensions are 90mm in height, 53mm in width, and 76mm in depth, allowing for compact installation.
It is designed for DIN rail mounting and uses screw terminals for secure wiring connections.
The enclosure has an IP20 rating, which protects the internal mechanism against accidental contact and solid foreign objects.
This model complies with IEC 60898, EN 60898, CSA C22.2 No.235, and UL 1077 standards.
It is suitable for industrial, residential, and functional building applications, providing protection against overloads and short circuits.
It features screw terminals, which facilitate secure and reliable wiring connections.
This miniature circuit breaker is manufactured in Germany.
Yes, supplementary components such as control switches and signal contacts can be combined with this MCB for customized protection solutions.
