Siemens SENTRON Miniature Circuit Breaker 3-Pole 20A Type C 400V AC 72V DC 6kA Breaking Capacity 5SY6320-7
Specifications
| Country of Origin | Germany |
|---|---|
| Range | SENTRON |
| Brand | Siemens |
| Height | 90mm |
| Model | 5SY6320-7 |
| Depth | 76mm |
| IP Rating | IP20 |
| Enclosure | IP20 equipment |
| Width | 53mm |
| Mount Type | DIN Rail |
| Current Rating | 20A |
| Series | 5SY6 |
| Breaking Capacity | 6kA |
| Number of Poles | 3 |
| Standards/Approvals | EN 60898 |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 72V dc |
| Tripping Characteristics | Type C |
| Better World Claim | Extended Product Life |
| Curve C | Tripping: 5 to 10 times the rated current |
| Curve D | Tripping: 10 to 14 times the rated current |
| Siemens MCB3P, 20A Curve CBrand | Siemens |
Key Features
- Designed for use in industrial, functional, and residential electrical applications.
- Supports DIN rail mounting and quick, convenient assembly and disassembly.
- Equipped with IP20 enclosure rating for protection against access to live parts.
- Complies with IEC 60898 and EN 60898 standards ensuring high reliability and safety.
- Offers tripping characteristics Type C suitable for protection of circuits with moderate inrush currents.
- Features an extended product life as part of Siemens Better World initiative.
- Breaking capacity of 6kA provides high short-circuit current interruption capability.
Product Description
Siemens 5SY6320-7 SENTRON Miniature Circuit Breaker is a high-quality 3-pole MCB designed for protection of electrical circuits with a nominal current rating of 20A and Type C tripping characteristic. It supports rated voltages up to 400V AC and 72V DC and can interrupt fault currents up to 6kA, ensuring safe operation in a variety of industrial, functional, and residential electrical installations.
This circuit breaker is suitable for mounting on DIN rails, supporting fast and convenient installation and removal. Its IP20 rated enclosure offers protection against accidental contact with live components, increasing operational safety.
Conforming to stringent international standards including IEC 60898 and EN 60898, this MCB ensures compliance and reliable performance. The Type C tripping curve makes it ideal for general applications where moderate inrush currents can occur such as protection of circuits with motors, transformers, and similar inductive loads.
The MCB measures 90 mm in height, 53 mm in width, and 76 mm in depth, making it compact for efficient panel space utilization. Siemens' commitment to sustainability is reflected in the extended product life of this device as part of their Better World initiative.
Industrial and residential electrical circuit protection. Quick DIN rail mounting enhances ease of installation. Type C tripping characteristic for circuit protection versatility. High breaking capacity of 6 kA for increased safety.
Compliance with IEC 60898 and EN 60898 standards. Compact dimensions fit standard electrical panels. IP20 enclosure rating prevents direct contact with live parts.
Siemens SENTRON 5SY6 series MCBs are trusted components in electrical distribution systems worldwide. For more products and technical details, explore the Siemens category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal current rating of this circuit breaker is 20A.
This unit supports rated voltages of up to 400V AC and 72V DC.
It has a breaking capacity of 6kA, allowing it to interrupt fault currents effectively.
It supports DIN rail mounting, facilitating quick and convenient installation and removal.
The enclosure has an IP20 rating, providing protection against access to live parts.
It complies with IEC 60898 and EN 60898 standards, ensuring reliable performance and safety.
The dimensions are 90 mm in height, 53 mm in width, and 76 mm in depth.
This circuit breaker features Type C tripping characteristics, suitable for circuits with moderate inrush currents.
It is designed for use in industrial, functional, and residential electrical applications.
The Better World claim indicates that this circuit breaker has an extended product life as part of Siemens' sustainability initiative.
This model is a 3-pole circuit breaker, providing versatile circuit protection.
The Type C tripping curve allows tripping at 5 to 10 times the rated current, suitable for various applications.
