Eaton 630A Bolted Tag Fuse C2 660 V AC, 450 V DC, Fixing Centres 133 mm TTM630

Eaton TTM630 bolted tag fuse is engineered for dependable low voltage circuit protection in industrial and commercial electrical systems. Featuring a 630A current rating with fuse size C2, it supports AC voltage up to 660 V and DC voltage up to 450 V, making it suitable for diverse applications including power distribution, automation, and control panels.

The fuse is designed with fixing centres of 133 mm and a tag width of 25.4 mm centered for secure mounting and easy fuse identification. Its high rupture capacity (HRC) characteristic guarantees safe interruption of high fault currents, protecting equipment and preventing electrical hazards.

Compact in dimension, with an overall length of 209.6 mm, diameter of 74.2 mm, height of 75 mm, and width of 75 mm, it fits neatly into standard fuse bases. Eaton's TTM series fuse, previously known under the Bussmann brand, conforms to strict international standards including RoHS, CE, and IEC 60269, ensuring high safety and environmental compliance.

Manufactured in Hungary, this fuse provides consistent performance and durability, suitable for industrial automation, electrical distribution boards, manufacturing facilities, and large-scale electrical installations. The robust construction supports long service life even in demanding environments.

Applications include power transformers, motor protection, switchgear, and control circuits requiring reliable overload and short-circuit protection. Eaton's bolted tag fuse offers an industrial-grade solution for engineers and electricians looking for safety and operational efficiency.

Rated current of 630 amperes ensures reliable circuit protection. Fuse size C2 suitable for standard fuse holders and switchgear. Voltage ratings of 660 V AC and 450 V DC for versatile industrial use. Fixing centres measure 133 mm for accurate installation.

High rupture capacity (HRC) capable of interrupting high fault currents. Tag width of 25.4 mm with centred orientation for easy identification. Overall length of 209.6 mm and diameter of 74.2 mm for compact mounting. Eaton TTM series fuse, formerly known as Bussmann, compliant with RoHS, CE, and IEC 60269 standards.

Manufactured in Hungary ensuring quality and performance. Explore more from Eaton bolted Tag Fuses to find compatible and alternative models for your specific industrial needs on EnvMart.
